8672008CY Series
Manufacturer: ALPHA WIRE
Beta
⌘K
MULTI-PAIR 16COND 20AWG
| Part | Shield Material | Shield Coverage | Wire Gauge | Conductor Strand [custom] | Conductor Strand [custom] | Voltage | Conductor Material | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Number of Conductors | Jacket (Insulation) Material | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Ratings | Cable Type | Conductor Insulation | Shield Type | Features | Jacket Color | Length | Length | Length [x] | Length [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ALPHA WIRE | Aluminum Copper Tinned | 85 % 100 % | 20 AWG | 19 | 32 AWG | 300 VDC | Copper Tinned | 13.03 mm | 0.513 " | 16 | Poly-Vinyl Chloride (PVC) | 0.053 " | 1.346 mm | UL Style 20234 | Multi-Pair | Poly-Vinyl Chloride (PVC) | Braid Foil | Drain Wire Oil Resistant | Slate | 304.8 m | 1000 ft | ||
ALPHA WIRE | Aluminum Copper Tinned | 85 % 100 % | 20 AWG | 19 | 32 AWG | 300 VDC | Copper Tinned | 13.03 mm | 0.513 " | 16 | Poly-Vinyl Chloride (PVC) | 0.053 " | 1.346 mm | UL Style 20234 | Multi-Pair | Poly-Vinyl Chloride (PVC) | Braid Foil | Drain Wire Oil Resistant | Slate | ||||
 ALPHA WIRE | Aluminum Copper Tinned | 85 % 100 % | 20 AWG | 19 | 32 AWG | 300 VDC | Copper Tinned | 13.03 mm | 0.513 " | 16 | Poly-Vinyl Chloride (PVC) | 0.053 " | 1.346 mm | UL Style 20234 | Multi-Pair | Poly-Vinyl Chloride (PVC) | Braid Foil | Drain Wire Oil Resistant | Slate | 3.05 m | 10 ft | 100 ft | 30.5 m |
 ALPHA WIRE | Aluminum Copper Tinned | 85 % 100 % | 20 AWG | 19 | 32 AWG | 300 VDC | Copper Tinned | 13.03 mm | 0.513 " | 16 | Poly-Vinyl Chloride (PVC) | 0.053 " | 1.346 mm | UL Style 20234 | Multi-Pair | Poly-Vinyl Chloride (PVC) | Braid Foil | Drain Wire Oil Resistant | Slate | 152.4 m | 500 ft |
