2F Series

Manufacturer: LEMO

Catalog

CIRCULAR PUSH PULL CONNECTORS RECEPTACLE W. NUT

Part	Material Flammability Rating	Contact Finish - Mating	Shielding	Mounting Feature	Applications	Primary Material	Shell Finish	Orientation	Contact Material	Insert Material	Shell Material	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Number of Positions	Operating Temperature [Min]	Operating Temperature [Max]	Connector Type	Ingress Protection	Mounting Type	Current Rating (Amps)	Termination	Shell Size - Insert	Fastening Type	Color	Cable Opening	Cable Opening	Contact Finish Thickness - Mating [custom]	Contact Finish Thickness - Mating [custom]	Material	Accessory Type	For Use With/Related Products	Features
LEMO EEP.2F.312.XLM	UL94 V-0	Gold	Shielded	Bulkhead - Front Side Nut	Aerospace	Metal	Nickel	P	Bronze	Polyetheretherketone (PEEK)	Aluminum Alloy	1.5 Ám	59 Áin	12	-15 °C	200 °C	Receptacle Female Sockets	IP50 - Dust Protected	Panel Mount	7 A	Crimp	312	Push-Pull	Gray
LEMO PHN.2F.310.XLM	UL94 V-0	Gold	Shielded		Aerospace	Metal	Nickel	N (Normal)	Bronze	Polyetheretherketone (PEEK)	Aluminum Alloy	1.5 Ám	59 Áin	10	-15 °C	200 °C	Receptacle Female Sockets	IP67 - Dust Tight Waterproof	Free Hanging (In-Line)	8 A	Crimp	310	Push-Pull	Gray	0.551 "	14 mm
LEMO FGN.2F.319.YLC	UL94 V-0	Gold	Shielded		Aerospace	Metal	Nickel	N (Normal)	Brass	Polyetheretherketone (PEEK)	Aluminum Alloy			19	-15 °C	200 °C	Plug Male Pins	IP67 - Dust Tight Waterproof	Free Hanging (In-Line)	5 A	Crimp	319	Push-Pull	Gray	0.551 "	14 mm	39.4 µin	1 µm
LEMO FGN.2F.312.XLC	UL94 V-0	Gold	Shielded		Aerospace	Metal	Nickel	N (Normal)	Brass	Polyetheretherketone (PEEK)	Aluminum Alloy			12	-15 °C	200 °C	Plug Male Pins	IP67 - Dust Tight Waterproof	Free Hanging (In-Line)	7 A	Crimp	312	Push-Pull	Gray	0.551 "	14 mm	39.4 µin	1 µm
LEMO BFN.2F.100.PCSG																								Gray					Polyamide (PA) Nylon	Cap (Cover)	2F Series Plug	Dust Protected Lanyard Water Resistant
