846-009 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 9POS 0.125
| Part | Termination Rows | Material - Insulation | Contact Finish | Contact Type | Card Thickness [Max] | Card Thickness [Min] | Number of Positions | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Color | Number of Rows | Pitch | Pitch | Read Out | Termination | Number of Positions/Bay/Row | Operating Temperature [Max] | Operating Temperature [Min] | Gender | Card Type | Contact Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Gold | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 9 | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Right Angle Through Hole | 0.25 Ám | 10 Áin | Green | 1 | 3.18 mm | 0.125 in | Single | Solder | 9 | 125 °C | -40 C | Female | Non Specified - Single Edge | Copper Alloy |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Gold | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 9 | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | Through Hole | 0.25 Ám | 10 Áin | Green | 1 | 3.18 mm | 0.125 in | Single | Wire Wrap | 9 | 125 °C | -40 C | Female | Non Specified - Single Edge | Copper Alloy |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Gold | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 9 | 4-40 Threaded Insert Top Mount Opening | Through Hole | 0.25 Ám | 10 Áin | Green | 1 | 3.18 mm | 0.125 in | Single | Solder | 9 | 125 °C | -40 C | Female | Non Specified - Single Edge | Copper Alloy | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Gold | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 9 | Flush Mount M3 Threaded Insert Top Opening | Right Angle Through Hole | 0.25 Ám | 10 Áin | Green | 1 | 3.18 mm | 0.125 in | Single | Solder | 9 | 125 °C | -40 C | Female | Non Specified - Single Edge | Copper Alloy | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Gold | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 9 | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | 0.25 Ám | 10 Áin | Green | 1 | 3.18 mm | 0.125 in | Single | Solder | 9 | 125 °C | -40 C | Female | Non Specified - Single Edge | Copper Alloy | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Gold | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 9 | Through Hole | 0.25 Ám | 10 Áin | Green | 1 | 3.18 mm | 0.125 in | Single | Wire Wrap | 9 | 125 °C | -40 C | Female | Non Specified - Single Edge | Copper Alloy | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Gold | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 9 | 4-40 Threaded Insert Top Mount Opening | Through Hole | 0.25 Ám | 10 Áin | Green | 1 | 3.18 mm | 0.125 in | Single | Solder | 9 | 125 °C | -40 C | Female | Non Specified - Single Edge | Copper Alloy | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Gold | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 9 | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | Right Angle Through Hole | 0.25 Ám | 10 Áin | Green | 1 | 3.18 mm | 0.125 in | Single | Solder | 9 | 125 °C | -40 C | Female | Non Specified - Single Edge | Copper Alloy |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Gold | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 9 | M3 Threaded Insert Top Mount Opening | Through Hole | 0.25 Ám | 10 Áin | Green | 1 | 3.18 mm | 0.125 in | Single | Solder | 9 | 125 °C | -40 C | Female | Non Specified - Single Edge | Copper Alloy | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Gold | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 9 | 3.25 mm | 0.128 " | Through Hole | 0.25 Ám | 10 Áin | Green | 1 | 3.18 mm | 0.125 in | Single | Solder | 9 | 125 °C | -40 C | Female | Non Specified - Single Edge | Copper Alloy |
