837-038 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 38POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Contact Material | Color | Card Thickness [Max] | Card Thickness [Min] | Operating Temperature [Max] | Operating Temperature [Min] | Number of Rows [custom] | Number of Positions/Bay/Row | Contact Finish | Pitch | Pitch | Card Type | Mounting Type | Gender | Termination | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish Thickness | Contact Finish Thickness | Contact Type | Number of Positions | Read Out | Termination Rows | Number of Rows | Number of Positions/Bay/Row [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 2 | 19 | Gold | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Through Hole | Female | Wire Wrap | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 0.25 Ám | 10 Áin | Cantilever | 38 | Dual | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Gold | 3.96 mm | 0.156 in | Non Specified - Single Edge | Through Hole | Female | Wire Wrap | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | 0.25 Ám | 10 Áin | Cantilever | 38 | Single | 1 | 1 | 38 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 2 | 19 | Gold | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Board Edge Straddle Mount | Female | Solder | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 0.25 Ám | 10 Áin | Cantilever | 38 | Dual | Card Extender | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Gold | 3.96 mm | 0.156 in | Non Specified - Single Edge | Through Hole | Female | Solder | Flush Mount M3 Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Cantilever | 38 | Single | 1 | 1 | 38 | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 2 | 19 | Gold | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Through Hole | Female | Wire Wrap | M3 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | Cantilever | 38 | Dual | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 2 | 19 | Gold | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Board Edge Straddle Mount | Female | Solder | 4-40 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | Cantilever | 38 | Dual | Card Extender | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 2 | 19 | Gold | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Through Hole | Female | Solder | 0.25 Ám | 10 Áin | Cantilever | 38 | Dual | |||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Gold | 3.96 mm | 0.156 in | Non Specified - Single Edge | Right Angle Through Hole | Female | Solder | M3 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | Cantilever | 38 | Single | 1 | 1 | 38 | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Gold | 3.96 mm | 0.156 in | Non Specified - Single Edge | Right Angle Through Hole | Female | Solder | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 0.25 Ám | 10 Áin | Cantilever | 38 | Single | 1 | 1 | 38 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Gold | 3.96 mm | 0.156 in | Non Specified - Single Edge | Through Hole | Female | Wire Wrap | 0.156 " | 3.96 mm | 0.25 Ám | 10 Áin | Cantilever | 38 | Single | 1 | 1 | 38 |
