G2RV-SL Series
Manufacturer: Omron Electronics Inc-EMC Div
Beta
⌘K
RELAY GEN PURPOSE SPDT 6A 24V
| Part | Termination Style | Must Operate Voltage | Switching Voltage | Operating Temperature [Min] | Operating Temperature [Max] | Contact Rating (Current) | Coil Voltage | Load - Max Switching | Relay Type | Contact Form | Coil Type | Must Release Voltage | Mounting Type | Approval Agency | Operate Time | Coil Current | Features | Contact Material | Coil Resistance |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Omron Electronics Inc-EMC Div | Spring Terminal | 19.2 VAC | 125 VDC 440 VAC | -40 °C | 55 °C | 6 A | 24 VAC | 750 W 2640 VA | General Purpose | SPDT (1 Form C) | Non Latching | 2.4 VAC/DC | DIN Rail | CE cULus TUV | 20 ms | 13 mA | Socket Included | Silver Tin Indium (AgSnIn) | |
Omron Electronics Inc-EMC Div | Screw Terminal | 38.4 VAC | 30 VAC 36 VDC | -40 °C | 55 °C | 50 mA | 48 VAC/DC | General Purpose | SPDT (1 Form C) | Non Latching | 4.8 VAC | DIN Rail | CE cULus TUV | 20 ms | 5.2 mA | Socket Included | 9231 Ohms | ||
 Omron Electronics Inc-EMC Div | Screw Terminal | 19.2 VDC | 125 VDC 440 VAC | -40 °C | 55 °C | 6 A | 24 VDC | 750 W 2640 VA | General Purpose | SPDT (1 Form C) | Non Latching | 2.4 VDC | DIN Rail | CE cULus TUV | 20 ms | 13.3 mA | Socket Included | ||
 Omron Electronics Inc-EMC Div | Spring Terminal | 19.2 VDC | 125 VDC 440 VAC | -40 °C | 55 °C | 6 A | 24 VDC | 750 W 2640 VA | General Purpose | SPDT (1 Form C) | Non Latching | 2.4 VDC | DIN Rail | CE cULus TUV | 20 ms | 13.3 mA | Socket Included Test Button | ||
 Omron Electronics Inc-EMC Div | Spring Terminal | 9.6 VDC | 125 VDC 440 VAC | -40 °C | 55 °C | 6 A | 12 VDC | 750 W 2640 VA | General Purpose | SPDT (1 Form C) | Non Latching | 1.2 VDC | DIN Rail | CE cULus TUV | 20 ms | 27.2 mA | Socket Included | Silver Tin Indium (AgSnIn) | 441.2 Ohms |
 Omron Electronics Inc-EMC Div | Screw Terminal | 9.6 VDC | 125 VDC 440 VAC | -40 °C | 55 °C | 6 A | 12 VDC | 750 W 2640 VA | General Purpose | SPDT (1 Form C) | Non Latching | 1.2 VDC | DIN Rail | CE cULus TUV | 20 ms | 27.2 mA | Socket Included | 441.2 Ohms | |
 Omron Electronics Inc-EMC Div | Spring Terminal | 88 VAC/DC | 30 VAC 36 VDC | -40 °C | 55 °C | 50 mA | 110 VAC/DC | General Purpose | SPDT (1 Form C) | Non Latching | 11 VAC | DIN Rail | CE cULus TUV | 20 ms | 7.1 mA | Socket Included | Gold (Au) Silver Tin Indium (AgSnIn) | 15493 Ohms | |
Omron Electronics Inc-EMC Div | Spring Terminal | 38.4 VAC | 30 VAC 36 VDC | -40 °C | 55 °C | 50 mA | 48 VAC/DC | General Purpose | SPDT (1 Form C) | Non Latching | 4.8 VAC | DIN Rail | CE cULus TUV | 20 ms | 5.2 mA | Socket Included | Gold (Au) Silver Tin Indium (AgSnIn) | 9231 Ohms | |
Omron Electronics Inc-EMC Div | Spring Terminal | 19.2 VDC | 30 VAC 36 VDC | -40 °C | 55 °C | 50 mA | 24 VDC | General Purpose | SPDT (1 Form C) | Non Latching | 2.4 VDC | DIN Rail | CE cULus TUV | 20 ms | 13.3 mA | Socket Included | Gold (Au) Silver Tin Indium (AgSnIn) | 1805 Ohms | |
 Omron Electronics Inc-EMC Div | Spring Terminal | 38.4 VAC | 125 VDC 440 VAC | -40 °C | 55 °C | 6 A | 48 VAC/DC | 750 W 2640 VA | General Purpose | SPDT (1 Form C) | Non Latching | 4.8 VAC | DIN Rail | CE cULus TUV | 20 ms | 5.2 mA | Socket Included | Silver Tin Indium (AgSnIn) | 9.23 kOhms |
