887-032 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 32POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Contact Material | Operating Temperature [Max] | Operating Temperature [Min] | Card Type | Card Thickness [Max] | Card Thickness [Min] | Number of Positions/Bay/Row | Contact Type | Mounting Type | Read Out | Contact Finish | Pitch | Pitch | Termination | Features | Flange Feature | Gender | Contact Finish Thickness | Contact Finish Thickness | Color | Number of Rows [custom] | Flange Feature [diameter] | Flange Feature [diameter] | Termination Rows | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Copper Alloy | 125 °C | -40 C | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 16 | Cantilever | Board Edge Straddle Mount | Dual | Gold | 3.96 mm | 0.156 in | Solder | Card Extender | Flush Mount M3 Threaded Insert Top Opening | Female | 0.25 Ám | 10 Áin | Black | 2 | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Copper Alloy | 125 °C | -40 C | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 16 | Cantilever | Board Edge Straddle Mount | Dual | Gold | 3.96 mm | 0.156 in | Solder | Card Extender | Flush Mount Top Opening Unthreaded | Female | 0.25 Ám | 10 Áin | Black | 2 | 3.25 mm | 0.128 " | ||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Copper Alloy | 125 °C | -40 C | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 16 | Cantilever | Through Hole | Dual | Gold | 3.96 mm | 0.156 in | Solder Eyelet(s) | Side Mount Opening Unthreaded | Female | 0.25 Ám | 10 Áin | Black | 2 | 3.25 mm | 0.128 " | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Copper Alloy | 125 °C | -40 C | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 32 | Cantilever | Through Hole | Single | Gold | 3.96 mm | 0.156 in | Wire Wrap | 4-40 Flush Mount Threaded Insert Top Opening | Female | 0.25 Ám | 10 Áin | Black | 1 | 1 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Copper Alloy | 125 °C | -40 C | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 32 | Cantilever | Through Hole | Single | Gold | 3.96 mm | 0.156 in | Solder | 4-40 Threaded Insert Top Mount Opening | Female | 0.25 Ám | 10 Áin | Black | 1 | 1 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Copper Alloy | 125 °C | -40 C | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 32 | Cantilever | Through Hole | Single | Gold | 3.96 mm | 0.156 in | Solder Eyelet(s) | Flush Mount M3 Threaded Insert Top Opening | Female | 0.25 Ám | 10 Áin | Black | 1 | 1 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Copper Alloy | 125 °C | -40 C | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 32 | Cantilever | Through Hole | Single | Gold | 3.96 mm | 0.156 in | Solder | Flush Mount M3 Threaded Insert Top Opening | Female | 0.25 Ám | 10 Áin | Black | 1 | 1 | |||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Copper Alloy | 125 °C | -40 C | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 16 | Cantilever | Through Hole | Dual | Gold | 3.96 mm | 0.156 in | Wire Wrap | Female | 0.25 Ám | 10 Áin | Black | 2 | 3.96 mm | 0.156 " | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Copper Alloy | 125 °C | -40 C | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 16 | Cantilever | Through Hole | Dual | Gold | 3.96 mm | 0.156 in | Wire Wrap | M3 Threaded Insert Top Mount Opening | Female | 0.25 Ám | 10 Áin | Black | 2 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Copper Alloy | 125 °C | -40 C | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 32 | Cantilever | Through Hole | Single | Gold | 3.96 mm | 0.156 in | Solder | Flush Mount Side Opening Unthreaded | Female | 0.25 Ám | 10 Áin | Black | 3.25 mm | 0.128 " | 1 | 1 |
