325-038 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 38POS 0.100
| Part | Material - Insulation | Termination Rows | Contact Finish | Gender | Color | Contact Material | Termination | Read Out | Operating Temperature [Min] | Operating Temperature [Max] | Flange Feature | Card Thickness | Card Thickness | Card Type | Mounting Type | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Pitch | Pitch | Number of Positions/Bay/Row [custom] | Number of Rows | Termination Rows [custom] | Number of Positions/Bay/Row | Number of Rows [custom] | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | Female | Green | Copper Alloy | Wire Wrap | Single | -65 ░C | 125 °C | 4-40 Flush Mount Threaded Insert Top Opening | 3.18 mm | 0.125 in | Non Specified - Single Edge | Through Hole | Cantilever | 0.25 Ám | 10 Áin | 38 | 0.1 " | 2.54 mm | 38 | 1 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Gold | Female | Green | Copper Alloy | Solder Eyelet(s) | Dual | -65 ░C | 125 °C | Flush Mount Top Opening Unthreaded | 3.18 mm | 0.125 in | Non Specified - Dual Edge | Through Hole | Cantilever | 0.25 Ám | 10 Áin | 38 | 0.1 " | 2.54 mm | 2 | 19 | 2 | 0.16 " | 4.06 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Gold | Female | Green | Copper Alloy | Wire Wrap | Dual | -65 ░C | 125 °C | Flush Mount Top Opening Unthreaded | 3.18 mm | 0.125 in | Non Specified - Dual Edge | Through Hole | Cantilever | 0.25 Ám | 10 Áin | 38 | 0.1 " | 2.54 mm | 2 | 19 | 2 | 0.16 " | 4.06 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Gold | Female | Green | Copper Alloy | Solder | Dual | -65 ░C | 125 °C | Flush Mount M3 Threaded Insert Top Opening | 3.18 mm | 0.125 in | Non Specified - Dual Edge | Through Hole | Cantilever | 0.25 Ám | 10 Áin | 38 | 0.1 " | 2.54 mm | 2 | 19 | 2 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Gold | Female | Green | Copper Alloy | Wire Wrap | Dual | -65 ░C | 125 °C | 3.18 mm | 0.125 in | Non Specified - Dual Edge | Through Hole | Cantilever | 0.25 Ám | 10 Áin | 38 | 0.1 " | 2.54 mm | 2 | 19 | 2 | ||||||
EDAC Inc. | Diallyl Phthalate (DAP) | Gold | Female | Green | Copper Alloy | Wire Wrap | Dual | -65 ░C | 125 °C | Flush Mount M3 Threaded Insert Top Opening | 3.18 mm | 0.125 in | Non Specified - Dual Edge | Through Hole | Cantilever | 0.25 Ám | 10 Áin | 38 | 0.1 " | 2.54 mm | 2 | 19 | 2 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | Female | Green | Copper Alloy | Solder | Single | -65 ░C | 125 °C | 3.18 mm | 0.125 in | Non Specified - Single Edge | Through Hole | Cantilever | 0.25 Ám | 10 Áin | 38 | 0.1 " | 2.54 mm | 38 | 1 | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | Female | Green | Copper Alloy | Wire Wrap | Single | -65 ░C | 125 °C | 3.18 mm | 0.125 in | Non Specified - Single Edge | Through Hole | Cantilever | 0.25 Ám | 10 Áin | 38 | 0.1 " | 2.54 mm | 38 | 1 | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Gold | Female | Green | Copper Alloy | Solder | Dual | -65 ░C | 125 °C | 3.18 mm | 0.125 in | Non Specified - Dual Edge | Through Hole | Cantilever | 0.25 Ám | 10 Áin | 38 | 0.1 " | 2.54 mm | 2 | 19 | 2 | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | Female | Green | Copper Alloy | Solder | Single | -65 ░C | 125 °C | Flush Mount Top Opening Unthreaded | 3.18 mm | 0.125 in | Non Specified - Single Edge | Through Hole | Cantilever | 0.25 Ám | 10 Áin | 38 | 0.1 " | 2.54 mm | 38 | 1 | 0.16 " | 4.06 mm |
