ESP32-D0 Series
Manufacturer: Espressif Systems
Beta
⌘K
IC RF TXRX+MCU BLE 48QFN
| Part | GPIO | Operating Temperature [Max] | Operating Temperature [Min] | Sensitivity | Package / Case | Frequency | Serial Interfaces | Data Rate (Max) [Max] | Type | Current - Transmitting | Memory Size | Supplier Device Package | Current - Receiving | RF Family/Standard | Power - Output | Mounting Type | Voltage - Supply [Min] | Voltage - Supply [Max] | Protocol |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Espressif Systems | 34 | 125 °C | -40 C | -98 dBm | 48-VFQFN Exposed Pad | 2.4 GHz | I2C I2S SPI UART | 150 Mbps | TxRx + MCU | 240 mA | 448 kB 520 kB | 48-QFN (6x6) | 100 mA | Bluetooth WiFi | 20 dBm | Surface Mount | 2.3 V | 3.6 V | 802.11b/g/n Bluetooth 4.2 |
Espressif Systems | 34 | 125 °C | -40 C | -98 dBm | 48-VFQFN Exposed Pad | 2.4 GHz | I2C I2S SPI UART | 150 Mbps | TxRx + MCU | 240 mA | 448 kB 520 kB | 48-QFN (5x5) | 100 mA | Bluetooth WiFi | 20 dBm | Surface Mount | 2.3 V | 3.6 V | 802.11b/g/n Bluetooth 4.2 |
