USB Connectors Mini USB 2.0 Interface
USB Connectors Mini USB 2.0 Interface
| Part | Number of Contacts | Mounting Feature | Shell/Shielding Material | Termination | Voltage - Rated | Operating Temperature [Max] | Operating Temperature [Min] | Mating Cycles | Mounting Type | Number of Ports | Connector Type | Insulation Color | Specifications | Shielding | Contact Finish | Gender | Material Flammability Rating | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Samtec Inc. | 5 | Horizontal | Copper Alloy | Solder | 30 V | 85 °C | -50 °C | 1500 | Surface Mount Right Angle | 1 | USB - mini B | Black | USB 2.0 | Unshielded | Gold | Receptacle | UL94 V-0 | Board Guide Pick and Place Solder Retention |
 Samtec Inc. | 5 | Horizontal | Copper Alloy | Solder | 30 V | 85 °C | -50 °C | 1500 | Surface Mount Right Angle | 1 | USB - mini B | Black | USB 2.0 | Unshielded | Gold | Receptacle | UL94 V-0 | Board Guide Pick and Place Solder Retention |
 Samtec Inc. | 5 | Horizontal | Copper Alloy | Solder | 30 V | 85 °C | -50 °C | 1500 | Surface Mount Right Angle | 1 | USB - mini B | Black | USB 2.0 | Unshielded | Gold | Receptacle | UL94 V-0 | Board Guide Solder Retention |
 Samtec Inc. | 5 | Horizontal | Copper Alloy | Solder | 30 V | 85 °C | -50 °C | 1500 | Surface Mount Right Angle | 1 | USB - mini B | Black | USB 2.0 | Unshielded | Gold | Receptacle | UL94 V-0 | Board Guide Pick and Place Solder Retention |
Samtec Inc. | 5 | Horizontal | Copper Alloy | Solder | 30 V | 85 °C | -50 °C | 1500 | Surface Mount Right Angle | 1 | USB - mini B | Black | USB 2.0 | Unshielded | Gold | Receptacle | UL94 V-0 | Board Guide Pick and Place Solder Retention |
Samtec Inc. | 5 | Horizontal | Copper Alloy | Solder | Surface Mount Right Angle | 1 | USB - mini A | Black | USB 2.0 | Unshielded | Gold | Receptacle | UL94 V-0 | Board Guide Solder Retention | ||||
Samtec Inc. | 5 | Horizontal | Copper Alloy | Solder | 30 V | 85 °C | -50 °C | 1500 | Surface Mount Right Angle | 1 | Black | USB 2.0 | Unshielded | Gold | Receptacle | UL94 V-0 | Board Guide Pick and Place Solder Retention | |
 Samtec Inc. | 5 | Horizontal | Copper Alloy | Solder | 30 V | 85 °C | -50 °C | 1500 | Surface Mount Right Angle | 1 | Black | USB 2.0 | Unshielded | Gold | Receptacle | UL94 V-0 | Board Guide Pick and Place Solder Retention | |
 Samtec Inc. | 5 | Horizontal | Copper Alloy | Solder | 30 V | 85 °C | -50 °C | 1500 | Surface Mount Right Angle | 1 | USB - mini B | Black | USB 2.0 | Unshielded | Gold | Receptacle | UL94 V-0 | Board Guide Solder Retention |
 Samtec Inc. | 5 | Horizontal | Copper Alloy | Solder | 30 V | 85 °C | -50 °C | 1500 | Surface Mount Right Angle | 1 | USB - mini B | Black | USB 2.0 | Unshielded | Gold | Receptacle | UL94 V-0 | Board Guide Solder Retention |
