AUC0512 Series
Manufacturer: Delta Electronics
Beta
⌘K
DC FANS FAN, 50X15MM, 12VDC, 20.22CFM, 2.16W, 0.18A, 38.5DBA, SUPERFLO, 4LEADS, TACH/PWM
| Part | Voltage Range [Min] | Voltage Range [Max] | Material - Blade | Material - Frame | Current Rating (Amps) | Lifetime @ Temp. | Termination | Bearing Type | RPM | Weight [custom] | Weight [custom] | Width [y] | Noise | Features | Size / Dimension [x] | Size / Dimension [z] | Air Flow | Air Flow | Approval Agency | Fan Type | Static Pressure | Static Pressure | Voltage - Rated | Power (Watts) | Operating Temperature [Min] | Operating Temperature [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Delta Electronics | 10.8 VDC | 13.2 VDC | Plastic | Plastic | 270 mA | 30000 Hrs | 4 Wire Leads | Superflo | 7400 RPM | 20.41 g | 0.045 lb | 15 mm | 38.5 dB | Locked Rotor Protection PWM Control Speed Sensor (Tach) | 50 mm | 50 mm | 0.566 m³/min | 20.2 CFM | CE CSA UL VDE | Tubeaxial | 74.5 Pa | 0.299 in H2O | 12 VDC | 2.16 W | -10 °C | 60 °C |
