21458-24 Series

Manufacturer: CNC Tech

Catalog

CABLE 2COND 24AWG BLK/RED 50'

Part	Length [x]	Length [x]	Conductor Material	Length	Length	Cable Type	Operating Temperature [Min]	Operating Temperature [Max]	Conductor Strand [custom]	Conductor Strand [custom]	Ratings	Wire Gauge	Voltage	Jacket (Insulation) Material	Jacket (Insulation) Thickness [x]	Jacket (Insulation) Thickness [x]	Number of Conductors	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Jacket Color	Conductor Strand [custom]
CNC Tech 21458-24-2-0500-0104-1-TS	7.62 m 30.5 m	25 ft 100 ft	Copper Tinned	15.24 m 152.4 m	50 ft 500 ft	Multi-Conductor	-10 °C	80 °C	0.0063 in	11	UL Style 21458	24 AWG	300 VDC	Polyphenylene Ether (PPE)	0.381 mm	0.015 in	2	2.89 mm	0.114 "	Black Red
CNC Tech 21458-24-2-0500-0402-1-TS	7.62 m 30.5 m	25 ft 100 ft	Copper Tinned	15.24 m 152.4 m	50 ft 500 ft	Multi-Conductor	-10 °C	80 °C	0.0063 in	11	UL Style 21458	24 AWG	300 VDC	Polyphenylene Ether (PPE)	0.381 mm	0.015 in	2	2.72 mm 2.89 mm	0.107 in 0.114 "	Red White	34 AWG
CNC Tech 21458-24-2-0500-0102-1-TS	7.62 m 30.5 m	25 ft 100 ft	Copper Tinned	15.24 m 152.4 m	50 ft 500 ft	Multi-Conductor	-10 °C	80 °C	0.0063 in	11	UL Style 21458	24 AWG	300 VDC	Polyphenylene Ether (PPE)	0.381 mm	0.015 in	2	2.89 mm	0.114 "	Black White
