tl6215 Series
Manufacturer: E-Switch
Beta
⌘K
MICROSWITCH TACT; SPST-NO; POS: 2; 0.05A/12VDC; THT; NONE; 4.5N
| Part | Contact Rating @ Voltage | Mounting Type | Actuator Orientation | Illumination | Circuit | Outline [x] | Outline [y] | Termination Style | Ingress Protection | Switch Function | Operating Temperature [Min] | Operating Temperature [Max] | Actuator Type | Actuator Height off PCB, Vertical [z] | Operating Force | Illumination Voltage (Nominal) | Illumination Type, Color |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 E-Switch | 0.05 A 12 VDC | Through Hole | Top Actuated | Non-Illuminated | SPST-NO | 7.7 mm | 6.37 mm | PC Pin | IP67 - Dust Tight Waterproof | Off-Mom | -20 ░C | 70 °C | Oval Button | 10.5 mm | 450 gf | ||
 E-Switch | 0.05 A 12 VDC | Through Hole | Top Actuated | Illuminated | SPST-NO | 7.7 mm | 6.37 mm | PC Pin | IP67 - Dust Tight Waterproof | Off-Mom | -20 ░C | 70 °C | Oval Button | 10.5 mm | 0.2 kgf | 2.1 VDC | Green LED |
