087089 Series

Manufacturer: Molex

Catalog

CONN HEADER VERT 40POS 2MM

Part	Style	Insulation Material	Shrouding	Contact Length - Post	Contact Length - Post	Material Flammability Rating	Applications	Connector Type	Number of Positions Loaded	Number of Rows	Contact Length - Mating	Contact Length - Mating	Termination	Insulation Color	Contact Type	Contact Shape	Fastening Type	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Finish - Mating	Contact Finish - Post	Contact Material	Row Spacing - Mating	Row Spacing - Mating	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Overall Contact Length [x]	Overall Contact Length [x]	Pitch - Mating [x]	Pitch - Mating [x]	Number of Positions	Insulation Height	Insulation Height	Mounting Type
Molex 0870894016	Board to Cable/Wire	Glass Filled Nylon 4/6 Polyamide (PA46)	Unshrouded	0.102 in	2.6 mm	UL94 V-0	Automotive General Purpose Telecommunications	Breakaway Header	All	2	4 mm	0.157 in	Solder	Black	Male Pin	Square	Push-Pull	74.8 Áin	1.9 Ám	Gold	Tin-Lead	Phosphor Bronze	0.079 in	2 mm	15 µin	0.38 µm	8.1 mm	0.319 in	0.079 in	2 mm	40	1.5 mm	0.059 "	Through Hole
Molex 0870893816	Board to Cable/Wire	Glass Filled Nylon 4/6 Polyamide (PA46)	Unshrouded	0.102 in	2.6 mm	UL94 V-0	Automotive General Purpose Telecommunications	Breakaway Header	All	2	4 mm	0.157 in	Solder	Black	Male Pin	Square	Push-Pull	74.8 Áin	1.9 Ám	Gold	Tin-Lead	Phosphor Bronze	0.079 in	2 mm	15 µin	0.38 µm	8.1 mm	0.319 in	0.079 in	2 mm	38	1.5 mm	0.059 "	Through Hole
Molex 0870893416	Board to Cable/Wire	Glass Filled Nylon 4/6 Polyamide (PA46)	Unshrouded	0.102 in	2.6 mm	UL94 V-0	Automotive General Purpose Telecommunications	Breakaway Header	All	2	4 mm	0.157 in	Solder	Black	Male Pin	Square	Push-Pull	74.8 Áin	1.9 Ám	Gold	Tin-Lead	Phosphor Bronze	0.079 in	2 mm	15 µin	0.38 µm	8.1 mm	0.319 in	0.079 in	2 mm	34	1.5 mm	0.059 "	Through Hole
Molex 0870891016	Board to Cable/Wire	Glass Filled Nylon 4/6 Polyamide (PA46)	Unshrouded	0.102 in	2.6 mm	UL94 V-0	Automotive General Purpose Telecommunications	Breakaway Header	All	2	4 mm	0.157 in	Solder	Black	Male Pin	Square	Push-Pull	74.8 Áin	1.9 Ám	Gold	Tin-Lead	Phosphor Bronze	0.079 in	2 mm	15 µin	0.38 µm	8.1 mm	0.319 in	0.079 in	2 mm	10	1.5 mm	0.059 "	Through Hole
