19001 Series
Manufacturer: Grayhill Inc.
Beta
⌘K
SWITCH ROTARY 7POS 15A 120V
| Part | Circuit per Deck | Number of Positions | Voltage Rating - DC | Current Rating (Amps) | Depth Behind Panel [z] | Index Stops | Number of Poles per Deck | Contact Material | Mounting Type | Actuator Length [x] | Contact Timing | Voltage Rating - AC | Actuator Type | Termination Style | Angle of Throw | Number of Decks [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Grayhill Inc. | SP7T | 7 | 120 V | 1 A 15 A | 24.13 mm | Fixed | 1 | Silver Alloy | Panel Mount | 0.5 in | Non-Shorting (BBM) | 120 V | Flatted (6.35mm Dia) | Solder Lug | 30 ° | 1 |
 Grayhill Inc. | SPDT | 2 | 120 V | 1 A 15 A | 24.13 mm | Fixed | 1 | Silver Alloy | Panel Mount | 0.5 in | Non-Shorting (BBM) | 120 V | Flatted (6.35mm Dia) | Solder Lug | 30 ° | 1 |
 Grayhill Inc. | SP4T | 4 | 120 V | 1 A 15 A | 24.13 mm | Fixed | 1 | Silver Alloy | Panel Mount | 0.5 in | Non-Shorting (BBM) | 120 V | Flatted (6.35mm Dia) | Solder Lug | 30 ° | 1 |
 Grayhill Inc. | SP6T | 6 | 120 V | 1 A 15 A | 24.13 mm | Fixed | 1 | Silver Alloy | Panel Mount | 0.5 in | Non-Shorting (BBM) | 120 V | Flatted (6.35mm Dia) | Solder Lug | 30 ° | 1 |
 Grayhill Inc. | SP3T | 120 V | 1 A 15 A | 24.13 mm | Fixed | 1 | Silver Alloy | Panel Mount | 0.5 in | Non-Shorting (BBM) | 120 V | Flatted (6.35mm Dia) | Solder Lug | 30 ° | 1 | |
 Grayhill Inc. | SP10T | 10 | 120 V | 1 A 15 A | 24.13 mm | Fixed | 1 | Silver Alloy | Panel Mount | 0.5 in | Non-Shorting (BBM) | 120 V | Flatted (6.35mm Dia) | Solder Lug | 30 ° | 1 |
