ERJ-PA Series

Manufacturer: Panasonic Industrial Automation Sales

Catalog

RES SMD 47 OHM 0.5% 1/3W 0603

...

Part	Composition	Package / Case	Resistance	Ratings	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Number of Terminations	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Power (Watts)	Power (Watts)	Operating Temperature [Max]	Operating Temperature [Min]	Temperature Coefficient	Features	Tolerance	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Supplier Device Package
Panasonic Industrial Automation Sales ERJ-PA3D47R0V	Thick Film	0603 (1608 Metric)	47 Ohms	AEC-Q200	0.022 in	0.55 mm	2	0.8 mm	0.063 in	1.6 mm	0.031 in	0.333 W	0.3333333333333333 W	155 °C	-55 °C	100 ppm/°C	Automotive AEC-Q200 Pulse Withstanding
Panasonic Industrial Automation Sales ERJ-PA3F34R8V	Thick Film	0603 (1608 Metric)		AEC-Q200	0.022 in	0.55 mm	2	0.8 mm	0.063 in	1.6 mm	0.031 in	0.333 W	0.3333333333333333 W	155 °C	-55 °C	100 ppm/°C	Automotive AEC-Q200 Pulse Withstanding	1 %
Panasonic Industrial Automation Sales ERJ-PA3D1690V	Thick Film	0603 (1608 Metric)	169 Ohms	AEC-Q200	0.022 in	0.55 mm	2	0.8 mm	0.063 in	1.6 mm	0.031 in	0.333 W	0.3333333333333333 W	155 °C	-55 °C	100 ppm/°C	Automotive AEC-Q200 Pulse Withstanding
Panasonic Industrial Automation Sales ERJ-PA3D2371V	Thick Film	0603 (1608 Metric)	2.37 kOhms	AEC-Q200	0.022 in	0.55 mm	2	0.8 mm	0.063 in	1.6 mm	0.031 in	0.333 W	0.3333333333333333 W	155 °C	-55 °C	100 ppm/°C	Automotive AEC-Q200 Pulse Withstanding
Panasonic Industrial Automation Sales ERJ-PA2F56R0X	Thick Film	0402 (1005 Metric)	56 Ohms	AEC-Q200			2	0.5 mm	0.039 in	1 mm	0.02 in	250 mW	0.25 W	155 °C	-55 °C	100 ppm/°C	Automotive AEC-Q200 Pulse Withstanding	1 %	0.016 in	0.4 mm	0402
Panasonic Industrial Automation Sales ERJ-PA3F1580V	Thick Film	0603 (1608 Metric)	158 Ohms	AEC-Q200	0.022 in	0.55 mm	2	0.8 mm	0.063 in	1.6 mm	0.031 in	0.333 W	0.3333333333333333 W	155 °C	-55 °C	100 ppm/°C	Automotive AEC-Q200 Pulse Withstanding	1 %
Panasonic Industrial Automation Sales ERJ-PA2F31R6X	Thick Film	0402 (1005 Metric)		AEC-Q200			2	0.5 mm	0.039 in	1 mm	0.02 in	250 mW	0.25 W	155 °C	-55 °C	100 ppm/°C	Automotive AEC-Q200 Pulse Withstanding	1 %	0.016 in	0.4 mm	0402
Panasonic Industrial Automation Sales ERJ-PA2D2741X	Thick Film	0402 (1005 Metric)	2.74 kOhms	AEC-Q200			2	0.5 mm	0.039 in	1 mm	0.02 in	250 mW	0.25 W	155 °C	-55 °C	100 ppm/°C	Automotive AEC-Q200 Pulse Withstanding		0.016 in	0.4 mm	0402
Panasonic Industrial Automation Sales ERJ-PA2D6800X	Thick Film	0402 (1005 Metric)	680 Ohms	AEC-Q200			2	0.5 mm	0.039 in	1 mm	0.02 in	250 mW	0.25 W	155 °C	-55 °C	100 ppm/°C	Automotive AEC-Q200 Pulse Withstanding		0.016 in	0.4 mm	0402
Panasonic Industrial Automation Sales ERJ-PA2F5110X	Thick Film	0402 (1005 Metric)	511 Ohms	AEC-Q200			2	0.5 mm	0.039 in	1 mm	0.02 in	250 mW	0.25 W	155 °C	-55 °C	100 ppm/°C	Automotive AEC-Q200 Pulse Withstanding	1 %	0.016 in	0.4 mm	0402
