581-M25 Series

Catalog

CONN MICRO-D FEMALE 25P RA PCB 3

Part	Voltage Rating	Contact Material	Operating Temperature [Max]	Operating Temperature [Min]	Color	Dielectric Material	Contact Finish Thickness	Contact Finish Thickness	Shell Material, Finish	Shell Material, Finish [custom]	Shell Material, Finish [custom]	Connector Style	Number of Rows [custom]	Current Rating (Amps)	Termination	Backset Spacing	Backset Spacing	Flange Feature	Contact Type	Number of Positions	Contact Finish	Connector Type	Mounting Type	Shell Size, Connector Layout [y]	Shell Size, Connector Layout [x]	Material Flammability Rating	Features
NorComp Inc. 581-M25-213L462	60 VDC	Brass	125 °C	-40 C	Black	Liquid Crystal Polymer (LCP)	30 Áin	0.76 Ám	Nickel Plated	Steel	Brass	D-Type Micro-D	2	2 A	Solder	0.22 in	5.6 mm	Board Side	Signal	25	Gold	Receptacle Female Sockets	Panel Mount Right Angle Through Hole	0.043 in	0.05 in	UL94 V-0	Board Lock Shielded
NorComp Inc. 581-M25-213L461	60 VDC	Brass	125 °C	-40 C	Black	Liquid Crystal Polymer (LCP)	15 µin	0.38 µm	Nickel Plated	Steel	Brass	D-Type Micro-D	2	2 A	Solder	0.22 in	5.6 mm	Board Side	Signal	25	Gold	Receptacle Female Sockets	Panel Mount Right Angle Through Hole	0.043 in	0.05 in	UL94 V-0	Board Lock Shielded
NorComp Inc. 581-M25-113L461	60 VDC	Brass	125 °C	-40 C	Black	Liquid Crystal Polymer (LCP)	15 µin	0.38 µm	Nickel Plated	Steel	Brass	D-Type Micro-D	2	2 A	Solder	0.22 in	5.6 mm	Board Side	Signal	25	Gold	Plug Male Pins	Panel Mount Right Angle Through Hole	0.043 in	0.05 in	UL94 V-0	Board Lock Shielded
NorComp Inc. 581-M25-113L462	60 VDC	Brass	125 °C	-40 C	Black	Liquid Crystal Polymer (LCP)	30 Áin	0.76 Ám	Nickel Plated	Steel	Brass	D-Type Micro-D	2	2 A	Solder	0.22 in	5.6 mm	Board Side	Signal	25	Gold	Plug Male Pins	Panel Mount Right Angle Through Hole	0.043 in	0.05 in	UL94 V-0	Board Lock Shielded
