PE4545 Series
Manufacturer: Pasternack
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
SMA(F) PCB VERT LAUNCH STRPLN
| Part | Dielectric Material | Center Contact Plating | Body Material | Mating Cycles | Housing Color | Connector Type | Impedance | Number of Ports | Mounting Feature | Frequency - Max | Shield Termination | Features | Center Contact Material | Connector Style | Mounting Type | Contact Termination | Fastening Type | Connector Plug Diameter | Operating Temperature (Max) | Operating Temperature (Min) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Pasternack | Polytetrafluoroethylene (PTFE) | Gold | Stainless Steel | 500 cycles | Silver | Female Socket Recepture | 50 Ohm | 1 | Flange | 26.5 GHz | Screw | Mounting Hardware | Beryllium Copper | SMA | Panel Mount | Clamp | Threaded | |||
 Pasternack | Polyetherimide (PEI) | Gold | Stainless Steel | 500 cycles | Silver | Male Pin Receptacle | 50 Ohm | 1 | Flange | 50 GHz | Screw | Mounting Hardware | Brass | APC-2.4 OS-50 | Panel Mount | Compression | Threaded | 2.4 mm | ||
 Pasternack | Polytetrafluoroethylene (PTFE) | Gold | Stainless Steel | 500 cycles | Silver | Female Socket Recepture | 50 Ohm | 1 | Flange | 26.5 GHz | Screw | Mounting Hardware | Beryllium Copper | SMA | Panel Mount | Clamp | Threaded | 135 °C | -40 °C | |
 Pasternack | Polyetherimide (PEI) | Gold | Stainless Steel | 500 cycles | Silver | Female Socket Recepture | 50 Ohm | 1 | Flange | 40 Gbps | Screw | Mounting Hardware | Beryllium Copper | Panel Mount | Compression | Threaded | 2.92 mm |
