627-9W4 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN D-SUB PLG 9POS PNL MNT SLDR
| Part | Dielectric Material | Contact Material | Color | Operating Temperature [Min] | Operating Temperature [Max] | Voltage Rating | Contact Finish Thickness | Contact Finish Thickness | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [x] | Number of Rows [custom] | Shell Material, Finish | Flange Feature | Material Flammability Rating | Connector Type | Features | Contact Finish | Contact Type | Number of Positions [Max] | Number of Positions [custom] | Number of Positions [custom] | Termination | Mounting Type | Connector Style | Contact Finish Thickness | Number of Positions [custom] | Number of Positions [custom] | Current Rating (Amps) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | Black | -55 C | 125 °C | 125 VDC | 30 Áin | 0.76 Ám | DB B - 9W4 | 3 | 2 | Nickel Plated Steel | M3 | UL94 V-0 | Plug Male Pins | Board Lock Grounding Indents Shielded | Gold | Signal and Power | 9 | 4 | 5 | Solder | Panel Mount Through Hole | Combo D-Sub | ||||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | Black | -55 C | 125 °C | 125 VDC | DB B - 9W4 | 3 | 2 | Nickel Plated Steel | Board Side (4-40) | UL94 V-0 | Plug Male Pins | Board Lock Grounding Indents Shielded | Gold | Signal and Power | Solder | Through Hole | Combo D-Sub | Flash | 4 | 5 | 10A 5A | |||||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | Black | -55 C | 125 °C | 125 VDC | 30 Áin | 0.76 Ám | DB B - 9W4 | 3 | 2 | Nickel Plated Steel | Housing/Shell (Unthreaded) | UL94 V-0 | Plug Male Pins | Grounding Indents Shielded | Gold | Signal and Power | Free Hanging (In-Line) | Combo D-Sub | 4 | 5 | 20A 5A | |||||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | Black | -55 C | 125 °C | 125 VDC | 30 Áin | 0.76 Ám | DB B - 9W4 | 3 | 2 | Housing/Shell (Unthreaded) | UL94 V-0 | Plug Male Pins | Grounding Indents Shielded | Gold | Signal and Power | Free Hanging (In-Line) | Combo D-Sub | 4 | 5 | 10A 5A | ||||||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | Black | -55 C | 125 °C | 125 VDC | DB B - 9W4 | 3 | 2 | Board Side (4-40) | UL94 V-0 | Plug Male Pins | Grounding Indents Shielded | Gold | Signal and Power | 9 | 4 | 5 | Free Hanging (In-Line) | Combo D-Sub | Flash | |||||||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | Black | -55 C | 125 °C | 125 VDC | DB B - 9W4 | 3 | 2 | Housing/Shell (Unthreaded) | UL94 V-0 | Plug Male Pins | Grounding Indents Shielded | Gold | Signal and Power | 9 | 4 | 5 | Free Hanging (In-Line) | Combo D-Sub | Flash | |||||||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | Black | -55 C | 125 °C | 125 VDC | 30 Áin | 0.76 Ám | DB B - 9W4 | 3 | 2 | Nickel Plated Steel | Board Side (M3) | UL94 V-0 | Plug Male Pins | Grounding Indents Shielded | Gold | Signal and Power | 9 | 4 | 5 | Solder | Panel Mount Through Hole | Combo D-Sub | ||||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | Black | -55 C | 125 °C | 125 VDC | DB B - 9W4 | 3 | 2 | Board Side (M3) | UL94 V-0 | Plug Male Pins | Grounding Indents Shielded | Gold | Signal and Power | Solder | Panel Mount Through Hole | Combo D-Sub | Flash | 4 | 5 | 10A 5A | ||||||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | Black | -55 C | 125 °C | 125 VDC | DB B - 9W4 | 3 | 2 | Nickel Plated Steel | Board Side (M3) | UL94 V-0 | Plug Male Pins | Grounding Indents Shielded | Gold | Signal and Power | Solder | Panel Mount Through Hole | Combo D-Sub | Flash | 4 | 5 | 10A 5A | |||||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | Black | -55 C | 125 °C | 125 VDC | 30 Áin | 0.76 Ám | DB B - 9W4 | 3 | 2 | Board Side (M3) | UL94 V-0 | Plug Male Pins | Grounding Indents Shielded | Gold | Signal and Power | 9 | 4 | 5 | Solder | Panel Mount Through Hole | Combo D-Sub |
