RP187 Series

Catalog

LINE FILTER 250VAC 1A CHASSIS

Part	Mounting Type	Current	Termination Style	Voltage - Rated AC	Operating Temperature [Max]	Operating Temperature [Min]	Approval Agency	Configuration	Frequency - Operating [Max]	Frequency - Operating [Min]	Filter Type	Applications
Astrodyne TDI RP187-1-2.2-W	Chassis Mount	1 A	IEC 320-C14 Wire Leads	250 V	100 °C	-25 °C	CE CSA cURus ENEC	Two Stage	60 Hz	50 Hz	Single Phase	General Purpose
Astrodyne TDI RP187-20-1-QD	Chassis Mount	20 A	IEC 320-C20 Quick Connect	250 V	100 °C	-25 °C	CE CSA cURus ENEC	Two Stage	60 Hz	50 Hz	Single Phase	General Purpose
Astrodyne TDI RP187-20-1-W	Chassis Mount	20 A	IEC 320-C20 Wire Leads	250 V	100 °C	-25 °C	CE CSA cURus ENEC	Two Stage	60 Hz	50 Hz	Single Phase	General Purpose
Astrodyne TDI RP187-6-2.2-QD	Chassis Mount	6 A	IEC 320-C14 Quick Connect	250 V	100 °C	-25 °C	CE CSA cURus ENEC	Two Stage	60 Hz	50 Hz	Single Phase	General Purpose
Astrodyne TDI RP187-3-2.2-QD	Chassis Mount	3 A	IEC 320-C14 Quick Connect	250 V	100 °C	-25 °C	CE CSA cURus ENEC	Two Stage	60 Hz	50 Hz	Single Phase	General Purpose
Astrodyne TDI RP187-20-2.2-QD	Chassis Mount	20 A	IEC 320-C20 Quick Connect	250 V	100 °C	-25 °C	CE CSA cURus ENEC	Two Stage	60 Hz	50 Hz	Single Phase	General Purpose
Astrodyne TDI RP187-10-4.7-W	Chassis Mount	10 A	IEC 320-C14 Wire Leads	250 V	100 °C	-25 °C	CE CSA cURus ENEC	Two Stage	60 Hz	50 Hz	Single Phase	General Purpose
Astrodyne TDI RP187-10-2.2-W	Chassis Mount	10 A	IEC 320-C14 Wire Leads	250 V	100 °C	-25 °C	CE CSA cURus ENEC	Two Stage	60 Hz	50 Hz	Single Phase	General Purpose
Astrodyne TDI RP187-10-2.2-QD	Chassis Mount	10 A	IEC 320-C14 Quick Connect	250 V	100 °C	-25 °C	CE CSA cURus ENEC	Two Stage	60 Hz	50 Hz	Single Phase	General Purpose
Astrodyne TDI RP187-10-0-QD	Chassis Mount	10 A	IEC 320-C14 Quick Connect	250 V	100 °C	-25 °C	CE CSA cURus ENEC	Two Stage	60 Hz	50 Hz	Single Phase	General Purpose
