PLP-45 Series
Manufacturer: MEAN WELL USA Inc.
Beta
⌘K
LED DRVR CC AC/DC 36-48V 950MA
| Part | Mounting Type | Topology | Type | Voltage - Input (Max) [Max] | Features | Operating Temperature [Min] | Operating Temperature [Max] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Termination Style | Efficiency | Approval Agency | Voltage - Output [Max] | Voltage - Output [Min] | Power (Watts) | Current - Output (Max) [Max] | Number of Outputs | Voltage - Input (Min) [Min] | Voltage - Isolation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 MEAN WELL USA Inc. | Chassis Mount | AC DC Converter | Constant Current | 264 VAC | OCP OVP SCP | -30 ░C | 70 °C | 29.6 mm | 50.8 mm | 1.17 " | 4 " | 2 in | 101.6 mm | Rectangular 2 Position | 89 % | CB CCC CE TUV UR | 48 V | 36 V | 46 W | 950 mA | 1 | 90 VAC | 3750 VDC |
MEAN WELL USA Inc. | Chassis Mount | AC DC Converter | Constant Current | 264 VAC | OCP OVP SCP | -30 ░C | 70 °C | 29.6 mm | 50.8 mm | 1.17 " | 4 " | 2 in | 101.6 mm | Rectangular 2 Position | 89 % | CB CCC CE cURus TUV | 24 V | 18 V | 46 W | 1.9 A | 1 | 90 VAC | 3750 VDC |
