614-93 Series
Manufacturer: Mill-Max Manufacturing Corp.
Beta
⌘K
CONN IC DIP SOCKET 18POS GOLD
| Part | Current Rating (Amps) | Termination Post Length | Termination Post Length | Pitch - Mating | Pitch - Mating | Housing Material | Termination | Mounting Type | Contact Finish - Mating | Features | Type | Type | Type | Pitch - Post | Pitch - Post | Contact Finish - Post | Contact Material - Mating | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Number of Positions or Pins (Grid) | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Contact Material - Post | Number of Positions or Pins (Grid) [y] | Number of Positions or Pins (Grid) [x] | Type [custom] | Type [custom] | Material Flammability Rating | Contact Resistance | Number of Positions or Pins (Grid) [custom] | Number of Positions or Pins (Grid) [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Mill-Max Manufacturing Corp. | 3 A | 4.19 mm | 0.165 " | 0.1 " | 2.54 mm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Solder | Through Hole | Gold | Carrier Open Frame | 7.62 mm | 0.3 in | DIP | 0.1 in | 2.54 mm | Tin-Lead | Beryllium Copper | 0.76 Ám | 30 Áin | 18 | -55 C | 125 °C | 200 µin | 5.08 µm | Brass Alloy | ||||||||
Mill-Max Manufacturing Corp. | 3 A | 3.45 mm | 0.136 in | 0.1 " | 2.54 mm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Solder | Through Hole | Gold | Carrier Open Frame | 7.62 mm | 0.3 in | DIP | 0.1 in | 2.54 mm | Tin-Lead | Beryllium Copper | 0.76 Ám | 30 Áin | 22 | -55 C | 125 °C | 200 µin | 5.08 µm | Brass Alloy | 11 | 2 | ||||||
Mill-Max Manufacturing Corp. | 3 A | 3.71 mm | 0.146 in | 0.1 " | 2.54 mm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Solder | Through Hole | Gold | Carrier Open Frame | 0.4 in | DIP | 0.1 in | 2.54 mm | Tin-Lead | Beryllium Copper | 0.76 Ám | 30 Áin | 22 | -55 C | 125 °C | 200 µin | 5.08 µm | Brass Alloy | 11 | 2 | |||||||
Mill-Max Manufacturing Corp. | 3 A | 4.19 mm | 0.165 " | 0.1 " | 2.54 mm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Solder | Through Hole | Gold | Carrier Open Frame | DIP | 0.1 in | 2.54 mm | Tin-Lead | Beryllium Copper | 0.76 Ám | 30 Áin | 24 | -55 C | 125 °C | 200 µin | 5.08 µm | Brass Alloy | 2 | 12 | 15.24 mm | 0.6 in | ||||||
Mill-Max Manufacturing Corp. | 3 A | 3.71 mm | 0.146 in | 0.1 " | 2.54 mm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Solder | Through Hole | Gold | Carrier Open Frame | 5.08 mm | DIP | 0.1 in | 2.54 mm | Tin-Lead | Beryllium Copper | 0.76 Ám | 30 Áin | 10 | -55 C | 125 °C | 200 µin | 5.08 µm | Brass Alloy | 5 | 2 | |||||||
Mill-Max Manufacturing Corp. | 3 A | 3.45 mm | 0.136 in | 0.1 " | 2.54 mm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Solder | Through Hole | Gold | Carrier Open Frame | DIP | 0.1 in | 2.54 mm | Tin-Lead | Beryllium Copper | 0.76 Ám | 30 Áin | 24 | -55 C | 125 °C | 200 µin | 5.08 µm | Brass Alloy | 2 | 12 | 15.24 mm | 0.6 in | UL94 V-0 | 10 mOhm | ||||
Mill-Max Manufacturing Corp. | 3 A | 3.71 mm | 0.146 in | 0.1 " | 2.54 mm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Solder | Through Hole | Gold | Carrier Open Frame | 7.62 mm | 0.3 in | DIP | 0.1 in | 2.54 mm | Tin-Lead | Beryllium Copper | 0.76 Ám | 30 Áin | 16 | -55 C | 125 °C | 200 µin | 5.08 µm | Brass Alloy | 2 | 8 | ||||||
Mill-Max Manufacturing Corp. | 3 A | 3.45 mm | 0.136 in | 0.1 " | 2.54 mm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Solder | Through Hole | Gold | Carrier Open Frame | 0.4 in | DIP | 0.1 in | 2.54 mm | Tin-Lead | Beryllium Copper | 0.76 Ám | 30 Áin | 24 | -55 C | 125 °C | 200 µin | 5.08 µm | Brass Alloy | 2 | 12 | |||||||
Mill-Max Manufacturing Corp. | 3 A | 3.45 mm | 0.136 in | 0.1 " | 2.54 mm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Solder | Through Hole | Gold | Carrier Open Frame | 7.62 mm | 0.3 in | DIP | 0.1 in | 2.54 mm | Tin-Lead | Beryllium Copper | 0.76 Ám | 30 Áin | 6 | -55 C | 125 °C | 200 µin | 5.08 µm | Brass Alloy | 3 positions or pins | 2 | UL94 V-0 | 10 mOhm | ||||
 Mill-Max Manufacturing Corp. | 3 A | 3.45 mm | 0.136 in | 0.1 " | 2.54 mm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Solder | Through Hole | Gold | Carrier Open Frame | 7.62 mm | 0.3 in | DIP | 0.1 in | 2.54 mm | Tin-Lead | Beryllium Copper | 0.76 Ám | 30 Áin | 16 | -55 C | 125 °C | 200 µin | 5.08 µm | Brass Alloy | 2 | 8 |
