1872A Series

Catalog

CAT6+ 4PRB U/UTP CMR REEL

Part	Conductor Material	Usage	Cable Type	Jacket (Insulation) Material	Features	Conductor Strand	Voltage	Number of Conductors	Conductor Insulation	Conductor Insulation	Length	Length	Jacket Color	Wire Gauge	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Ratings
Belden Inc. 1872A X6G1000	Copper Bare	Ethernet	Multi-Pair Cat6	Poly-Vinyl Chloride (PVC) Riser	Rip Cord	Solid	300 VDC	8	Polyolefin	PO	304.8 m	1000 ft	Gold	23 AWG	9.27 mm	0.365 in	UL Style CMR
Belden Inc. 1872A 005A1000	Copper Bare	Ethernet	Multi-Pair Cat6	Poly-Vinyl Chloride (PVC) Riser	Rip Cord	Solid	300 VDC	8	Polyolefin	PO	304.8 m	1000 ft	Green	23 AWG	9.27 mm	0.365 in	UL Style CMR
Belden Inc. 1872A 0061000	Copper Bare	Ethernet	Multi-Pair Cat6	Poly-Vinyl Chloride (PVC) Riser	Rip Cord	Solid	300 VDC	8	Polyolefin	PO	304.8 m	1000 ft	Blue	23 AWG	9.27 mm	0.365 in	UL Style CMR
Belden Inc. 1872A 006A1000	Copper Bare	Ethernet	Multi-Pair Cat6	Poly-Vinyl Chloride (PVC) Riser	Rip Cord	Solid	300 VDC	8	Polyolefin	PO	304.8 m	1000 ft	Blue	23 AWG	9.27 mm	0.365 in	UL Style CMR
Belden Inc. 1872A 0041000	Copper Bare	Ethernet	Multi-Pair Cat6	Poly-Vinyl Chloride (PVC) Riser	Rip Cord	Solid	300 VDC	8	Polyolefin	PO	304.8 m	1000 ft	Yellow	23 AWG	9.27 mm	0.365 in	UL Style CMR
Belden Inc. 1872A 0031000	Copper Bare	Ethernet	Multi-Pair Cat6	Poly-Vinyl Chloride (PVC) Riser	Rip Cord	Solid	300 VDC	8	Polyolefin	PO	304.8 m	1000 ft	Orange	23 AWG	9.27 mm	0.365 in	UL Style CMR
Belden Inc. 1872A F6H1000	Copper Bare	Ethernet	Multi-Pair Cat6	Poly-Vinyl Chloride (PVC) Riser	Rip Cord	Solid	300 VDC	8	Polyolefin	PO	304.8 m	1000 ft	Gray	23 AWG	9.27 mm	0.365 in	UL Style CMR
Belden Inc. 1872A 0021000	Copper Bare	Ethernet	Multi-Pair Cat6	Poly-Vinyl Chloride (PVC) Riser	Rip Cord	Solid	300 VDC	8	Polyolefin	PO	304.8 m	1000 ft	Red	23 AWG	9.27 mm	0.365 in	UL Style CMR
Belden Inc. 1872A 004A1000	Copper Bare	Ethernet	Multi-Pair Cat6	Poly-Vinyl Chloride (PVC) Riser	Rip Cord	Solid	300 VDC	8	Polyolefin	PO	304.8 m	1000 ft	Yellow	23 AWG	9.27 mm	0.365 in	UL Style CMR
Belden Inc. 1872A 007A1000	Copper Bare	Ethernet	Multi-Pair Cat6	Poly-Vinyl Chloride (PVC) Riser	Rip Cord	Solid	300 VDC	8	Polyolefin	PO	304.8 m	1000 ft	Purple	23 AWG	9.27 mm	0.365 in	UL Style CMR
