837-064 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 64POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Read Out | Contact Finish | Card Thickness [Max] | Card Thickness [Min] | Number of Positions | Contact Material | Contact Type | Pitch | Pitch | Contact Finish Thickness | Contact Finish Thickness | Number of Rows [custom] | Color | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Mounting Type | Card Type | Operating Temperature [Max] | Operating Temperature [Min] | Gender | Termination | Number of Positions/Bay/Row | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 64 | Copper Alloy | Cantilever | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 2 | Green | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Through Hole | Non Specified - Dual Edge | 125 °C | -40 C | Female | Solder | 32 | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 64 | Copper Alloy | Cantilever | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 2 | Green | Floating Bobbin Top Mount Opening | 2.95 mm | 0.116 " | Board Edge Straddle Mount | Non Specified - Dual Edge | 125 °C | -40 C | Female | Solder | 32 | Card Extender |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 64 | Copper Alloy | Cantilever | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 2 | Green | 4-40 Threaded Insert Top Mount Opening | Through Hole | Non Specified - Dual Edge | 125 °C | -40 C | Female | Solder | 32 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 64 | Copper Alloy | Cantilever | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 2 | Green | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | Non Specified - Dual Edge | 125 °C | -40 C | Female | Solder | 32 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 64 | Copper Alloy | Cantilever | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 2 | Green | Through Hole | Non Specified - Dual Edge | 125 °C | -40 C | Female | Wire Wrap | 32 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 64 | Copper Alloy | Cantilever | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 2 | Green | Flush Mount Side Opening Unthreaded | 3.25 mm | 0.128 " | Through Hole | Non Specified - Dual Edge | 125 °C | -40 C | Female | Solder | 32 | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 64 | Copper Alloy | Cantilever | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 2 | Green | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | Through Hole | Non Specified - Dual Edge | 125 °C | -40 C | Female | Wire Wrap | 32 | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 64 | Copper Alloy | Cantilever | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 2 | Green | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | Through Hole | Non Specified - Dual Edge | 125 °C | -40 C | Female | Solder | 32 | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 64 | Copper Alloy | Cantilever | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 2 | Green | 3.25 mm | 0.128 " | Board Edge Straddle Mount | Non Specified - Dual Edge | 125 °C | -40 C | Female | Solder | 32 | Card Extender | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 64 | Copper Alloy | Cantilever | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 2 | Green | 4-40 Threaded Insert Top Mount Opening | Board Edge Straddle Mount | Non Specified - Dual Edge | 125 °C | -40 C | Female | Solder | 32 | Card Extender |
