860-004 Series
Manufacturer: NorComp Inc.
Beta
⌘K
SENSOR CONNECTOR, VULCON SERIES, M12, FEMALE, 4 POSITIONS, PCB SOCKET, STRAIGHT PANEL MOUNT
| Part | Voltage Rating | Mounting Feature | Connector Type | Insert Material | Color | Current Rating (Amps) | Primary Material | Operating Temperature [Max] | Operating Temperature [Min] | Shell Material | Ingress Protection | Number of Positions | Mounting Type | Applications | Orientation | Fastening Type | Termination | Shell Finish | Material Flammability Rating | Contact Material | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Contact Finish - Mating | Shell Size - Insert | Shielding | Contact Finish Thickness - Mating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | 250 V | Bulkhead - Front Side Nut | Receptacle Male Pins | Polybutylene Terephthalate (PBT) | Silver | 4 A | Metal | 85 °C | -40 C | Brass | IP67 - Dust Tight Waterproof | 4 | Panel Mount Through Hole | Industrial Medical | A | Threaded | Solder | Nickel | UL94 V-0 | Brass | 0.25 µm | 10 µin | Gold | M12-4 | Shielded | |
 NorComp Inc. | 250 V | Bulkhead - Front Side Nut | Receptacle Male Pins | Polybutylene Terephthalate (PBT) | Silver | 4 A | Metal | 85 °C | -40 C | Brass | IP67 - Dust Tight Waterproof | 4 | Panel Mount Through Hole | Industrial Medical | A | Threaded | Solder | Nickel | UL94 V-0 | Brass | Gold | M12-4 | Shielded | Flash |
