CERAMIC COMPOSITION RESISTORS 5.5WATT 2.7OHM 10% HIGH ENERGY NON-IND.

Part	Operating Temperature [Min]	Operating Temperature [Max]	Package / Case	Composition	Supplier Device Package	Height - Seated (Max)	Height - Seated (Max) [Max] [z]	Size / Dimension [y]	Size / Dimension [x]	Number of Terminations	Resistance	Features	Tolerance	Height - Seated (Max) [Max] [z]	Power (Watts)	Number of Terminations [custom]	Size / Dimension [x]	Size / Dimension [y]	Height - Seated (Max) [Max] [custom]	Height - Seated (Max) [Max] [custom]	Size / Dimension	Size / Dimension [diameter]
Ohmite AZ27GKE	-55 C	150 °C	Radial	Ceramic	Radial Lead	26 mm	1.024 in	1.024 in 26 mm	1.181 " 30 mm	4	2.7 Ohms	Flame Retardant Coating Moisture Resistant Non-Inductive Pulse Withstanding Safety	10 %
Ohmite AX10GKE	-55 C	150 °C	Radial	Ceramic			1.102 in	21 mm	15 mm		1 Ohms	Flame Retardant Coating Moisture Resistant Non-Inductive Pulse Withstanding Safety	10 %	28 mm	3.5 W	2	0.591 in	0.827 in
Ohmite AX27GKE	-55 C	150 °C	Radial	Ceramic	Radial Lead		1.102 in	21 mm	15 mm		2.7 Ohms	Flame Retardant Coating Moisture Resistant Non-Inductive Pulse Withstanding Safety	10 %	28 mm	3.5 W	2	0.591 in	0.827 in
Ohmite AW121KE	-55 C	150 °C	Radial	Ceramic	Radial Lead			13 mm	20 mm		120 Ohms	Flame Retardant Coating Moisture Resistant Non-Inductive Pulse Withstanding Safety	10 %		2.5 W	2	0.787 "	0.512 "	0.866 in	22 mm
Ohmite AX22GKE	-55 C	150 °C	Radial	Ceramic	Radial Lead		1.102 in	21 mm	15 mm		2.2 Ohms	Flame Retardant Coating Moisture Resistant Non-Inductive Pulse Withstanding Safety	10 %	28 mm	3.5 W	2	0.591 in	0.827 in
Ohmite AX270KE	-55 C	150 °C	Radial	Ceramic			1.102 in	21 mm	15 mm		27 Ohms	Flame Retardant Coating Moisture Resistant Non-Inductive Pulse Withstanding Safety	10 %	28 mm	3.5 W	2	0.591 in	0.827 in
Ohmite AW47GKE	-55 C	150 °C	Radial	Ceramic	Radial Radial Lead			13 mm	20 mm		4.7 Ohms	Flame Retardant Coating Moisture Resistant Non-Inductive Pulse Withstanding Safety	10 %		2.5 W	2	0.787 "	0.512 "	0.866 in	22 mm	13 mm	0.512 in
Ohmite AW56GKE	-55 C	150 °C	Radial	Ceramic	Radial Lead			13 mm	20 mm		5.6 Ohms	Flame Retardant Coating Moisture Resistant Non-Inductive Pulse Withstanding Safety	10 %		2.5 W	2	0.787 "	0.512 "	0.866 in	22 mm
Ohmite AY120KE	-55 C	150 °C	Radial	Ceramic			1.102 in	21 mm	25 mm		12 Ohms	Flame Retardant Coating Moisture Resistant Non-Inductive Pulse Withstanding Safety	10 %	28 mm	4.5 W	2	0.984 "	0.827 in
