BLM15EG Series

Catalog

FERRITE BEAD 220 OHM 0402 1LN

Part	Current Rating (Max) [Max]	Height (Max) [z]	Height (Max) [z]	Features	DC Resistance (DCR) (Max) [Max]	Ratings	Package / Case	Operating Temperature [Min]	Operating Temperature [Max]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Filter Type	Number of Lines	Impedance @ Frequency	Mounting Type	DC Resistance (DCR) (Max)
Murata Electronics BLM15EG221SZ1D	700 mA	0.55 mm	0.022 in	Automotive	280 mOhm	AEC-Q200	0402 (1005 Metric)	-55 C	125 °C	0.02 in	0.5 mm	0.039 "	1 mm	Power Signal Line	1	220 Ohms	Surface Mount
Murata Electronics BLM15EG121SZ1D	1.5 A	0.55 mm	0.022 in	Automotive		AEC-Q200	0402 (1005 Metric)	-55 C	125 °C	0.02 in	0.5 mm	0.039 "	1 mm	Power Signal Line	1	120 Ohms	Surface Mount	95 mOhm
Murata Electronics BLM15EG121SN1D	1.5 A	0.55 mm	0.022 in				0402 (1005 Metric)	-55 C	125 °C	0.022 in	0.55 mm	0.039 "	1 mm		1	120 Ohms	Surface Mount	95 mOhm
Murata Electronics BLM15EG221SN1D	700 mA	0.55 mm	0.022 in		280 mOhm		0402 (1005 Metric)	-55 C	125 °C	0.022 in	0.55 mm	0.039 "	1 mm		1	220 Ohms	Surface Mount
