627-5W5 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN D-SUB PLUG 5POS SLDR CUP
| Part | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Voltage Rating | Dielectric Material | Color | Features | Connector Type | Flange Feature | Mounting Type | Contact Finish | Number of Rows | Material Flammability Rating | Current Rating (Amps) | Shell Size, Connector Layout [x] | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout | Connector Style | Contact Type | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Contact Finish Thickness | Termination | Shell Material, Finish | Flange Feature [custom] | Flange Feature [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Copper Alloy | -55 C | 125 °C | 125 VDC | Polyester Thermoplastic | Black | Grounding Indents Shielded | Plug Male Pins | Board Side (4-40) | Free Hanging (In-Line) | Gold | 1 | UL94 V-0 | 20 A | 3 | DB B | 5W5 | Combo D-Sub | Power | 5 | 30 Áin | 0.76 Ám | |||||
 EDAC Inc. | Copper Alloy | -55 C | 125 °C | 125 VDC | Polyester Thermoplastic | Black | Board Lock Grounding Indents Shielded | Plug Male Pins | Board Side (M3) | Through Hole | Gold | 1 | UL94 V-0 | 10 A | 3 | DB B | 5W5 | Combo D-Sub | Power | 5 | Flash | Solder | Nickel Plated Steel | ||||
 EDAC Inc. | Copper Alloy | -55 C | 125 °C | 125 VDC | Polyester Thermoplastic | Black | Grounding Indents Shielded | Plug Male Pins | M3 | Panel Mount | Gold | 1 | UL94 V-0 | 30 A | 3 | DB B | 5W5 | Combo D-Sub | Power | 5 | 30 Áin | 0.76 Ám | Solder | ||||
 EDAC Inc. | Copper Alloy | -55 C | 125 °C | 125 VDC | Polyester Thermoplastic | Black | Grounding Indents Shielded | Plug Male Pins | Board Side (M3) | Panel Mount | Gold | 1 | UL94 V-0 | 30 A | 3 | DB B | 5W5 | Combo D-Sub | Power | 5 | 30 Áin | 0.76 Ám | Solder | Nickel Plated Steel | |||
 EDAC Inc. | Copper Alloy | -55 C | 125 °C | 125 VDC | Polyester Thermoplastic | Black | Grounding Indents Shielded | Plug Male Pins | Panel Mount | Gold | 1 | UL94 V-0 | 40 A | 3 | DB B | 5W5 | Combo D-Sub | Power | 5 | Flash | Solder | Nickel Plated Steel | 4-40 | 4-40 | |||
 EDAC Inc. | Copper Alloy | -55 C | 125 °C | 125 VDC | Polyester Thermoplastic | Black | Grounding Indents Shielded | Plug Male Pins | M3 | Panel Mount | Gold | 1 | UL94 V-0 | 3 | DB B | 5W5 | Combo D-Sub | Coax | 5 | Flash | Solder | ||||||
 EDAC Inc. | Copper Alloy | -55 C | 125 °C | 125 VDC | Polyester Thermoplastic | Black | Board Lock Grounding Indents Shielded | Plug Male Pins | 4-40 | Panel Mount Through Hole | Gold | 1 | UL94 V-0 | 3 | DB B | 5W5 | Combo D-Sub | Coax | 5 | Flash | Solder | Nickel Plated Steel | |||||
 EDAC Inc. | Copper Alloy | -55 C | 125 °C | 125 VDC | Polyester Thermoplastic | Black | Grounding Indents Shielded | Plug Male Pins | Board Side (4-40) | Free Hanging (In-Line) | Gold | 1 | UL94 V-0 | 30 A | 3 | DB B | 5W5 | Combo D-Sub | Power | 5 | 30 Áin | 0.76 Ám | |||||
 EDAC Inc. | Copper Alloy | -55 C | 125 °C | 125 VDC | Polyester Thermoplastic | Black | Grounding Indents Shielded | Plug Male Pins | Housing/Shell (Unthreaded) | Through Hole | Gold | 1 | UL94 V-0 | 10 A | 3 | DB B | 5W5 | Combo D-Sub | Power | 5 | Flash | Solder | Nickel Plated Steel | ||||
 EDAC Inc. | Copper Alloy | -55 C | 125 °C | 125 VDC | Polyester Thermoplastic | Black | Grounding Indents Shielded | Plug Male Pins | Housing/Shell (Unthreaded) | Free Hanging (In-Line) | Gold | 1 | UL94 V-0 | 40 A | 3 | DB B | 5W5 | Combo D-Sub | Power | 5 | 30 Áin | 0.76 Ám | Nickel Plated Steel |
