PPT5 Series

Manufacturer: Bertech

Catalog

TAPE MASKING AMBER 3 1/2"X36YDS

Part	Usage	Thickness - Adhesive	Thickness - Adhesive	Thickness - Adhesive	Width	Width	Width	Thickness	Thickness	Thickness	Temperature Range [Min]	Temperature Range [Max]	Temperature Range [Max]	Temperature Range [Min]	Backing, Carrier	Length	Length	Length	Adhesive	Color	Tape Type	Thickness - Backing, Carrier [custom]	Thickness - Backing, Carrier [custom]	Thickness - Backing, Carrier [custom]	Width [x]	Width [x]	Width [y]	Width [y]	Width
Bertech PPT5-3 1/2	Flame Retardant High Temperature Masking UL Recognized	1.5 mils	0.038 mm	0.0015 in		3.5 in	88.9 mm	0.0065 in	0.165 mm	6.5 mils	-99 °F	260 °C	260 °C	-73 °C	Polyimide	32.9 m	108 ft	36 yd	Silicone	Amber	Masking	0.127 mm	0.005 in	5 mils
Bertech PPT5-2 1/2	Flame Retardant High Temperature Masking UL Recognized	1.5 mils	0.038 mm	0.0015 in				0.0065 in	0.165 mm	6.5 mils	-99 °F	260 °C	260 °C	-73 °C	Polyimide	32.9 m	108 ft	36 yd	Silicone	Amber	Masking	0.127 mm	0.005 in	5 mils	63.5 mm	2.5 in
Bertech PPT5-1 3/8	Flame Retardant High Temperature Masking UL Recognized	1.5 mils	0.038 mm	0.0015 in		1.38 in	34.93 mm	0.0065 in	0.165 mm	6.5 mils	-99 °F	260 °C	260 °C	-73 °C	Polyimide	32.9 m	108 ft	36 yd	Silicone	Amber	Masking	0.127 mm	0.005 in	5 mils
Bertech PPT5-75MM	Flame Retardant High Temperature Masking UL Recognized	1.5 mils	0.038 mm	0.0015 in				0.0065 in	0.165 mm	6.5 mils	-99 °F	260 °C	260 °C	-73 °C	Polyimide	32.9 m	108 ft	36 yd	Silicone	Amber	Masking	0.127 mm	0.005 in	5 mils	75 mm	2.95 in
Bertech PPT5-10MM	Flame Retardant High Temperature Masking UL Recognized	1.5 mils	0.038 mm	0.0015 in				0.0065 in	0.165 mm	6.5 mils	-99 °F	260 °C	260 °C	-73 °C	Polyimide	32.9 m	108 ft	36 yd	Silicone	Amber	Masking	0.127 mm	0.005 in	5 mils			10 mm	0.39 in
Bertech PPT5-1 3/4	Flame Retardant High Temperature Masking UL Recognized	1.5 mils	0.038 mm	0.0015 in		1.75 "	44.45 mm	0.0065 in	0.165 mm	6.5 mils	-99 °F	260 °C	260 °C	-73 °C	Polyimide	32.9 m	108 ft	36 yd	Silicone	Amber	Masking	0.127 mm	0.005 in	5 mils
Bertech PPT5-50MM	Flame Retardant High Temperature Masking UL Recognized	1.5 mils	0.038 mm	0.0015 in				0.0065 in	0.165 mm	6.5 mils	-99 °F	260 °C	260 °C	-73 °C	Polyimide	32.9 m	108 ft	36 yd	Silicone	Amber	Masking	0.127 mm	0.005 in	5 mils	50 mm	1.97 in
Bertech PPT5-1 5/8	Flame Retardant High Temperature Masking UL Recognized	1.5 mils	0.038 mm	0.0015 in		1.63 in	41.28 mm	0.0065 in	0.165 mm	6.5 mils	-99 °F	260 °C	260 °C	-73 °C	Polyimide	32.9 m	108 ft	36 yd	Silicone	Amber	Masking	0.127 mm	0.005 in	5 mils					1 5/8
Bertech PPT5-10	Flame Retardant High Temperature Masking UL Recognized	1.5 mils	0.038 mm	0.0015 in				0.0065 in	0.165 mm	6.5 mils	-99 °F	260 °C	260 °C	-73 °C	Polyimide	32.9 m	108 ft	36 yd	Silicone	Amber	Masking	0.127 mm	0.005 in	5 mils	254 mm	10 in
Bertech PPT5-11/16	Flame Retardant High Temperature Masking UL Recognized	1.5 mils	0.038 mm	0.0015 in	0.6875 in	0.69 in	17.48 mm	0.0065 in	0.165 mm	6.5 mils	-99 °F	260 °C	260 °C	-73 °C	Polyimide	32.9 m	108 ft	36 yd	Silicone	Amber	Masking	0.127 mm	0.005 in	5 mils
