887-030 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 30POS 0.156
| Part | Termination Rows | Material - Insulation | Flange Feature [diameter] | Flange Feature [diameter] | Contact Type | Contact Finish | Gender | Termination | Contact Material | Color | Read Out | Card Type | Number of Positions | Number of Rows | Pitch | Pitch | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions/Bay/Row | Contact Finish Thickness | Contact Finish Thickness | Card Thickness [Max] | Card Thickness [Min] | Mounting Type | Flange Feature | Termination Rows [custom] | Number of Rows [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.156 " | 3.96 mm | Cantilever | Gold | Female | Wire Wrap | Copper Alloy | Black | Single | Non Specified - Single Edge | 30 | 1 | 3.96 mm | 0.156 in | 125 °C | -40 C | 30 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | ||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.116 " | 2.95 mm | Cantilever | Gold | Female | Wire Wrap | Copper Alloy | Black | Single | Non Specified - Single Edge | 30 | 1 | 3.96 mm | 0.156 in | 125 °C | -40 C | 30 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Floating Bobbin Flush Mount | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.156 " | 3.96 mm | Cantilever | Gold | Female | Wire Wrap | Copper Alloy | Black | Dual | Non Specified - Dual Edge | 30 | 3.96 mm | 0.156 in | 125 °C | -40 C | 15 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Flush Mount Top Opening Unthreaded | 2 | 2 | |||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Cantilever | Gold | Female | Solder Eyelet(s) | Copper Alloy | Black | Single | Non Specified - Single Edge | 30 | 1 | 3.96 mm | 0.156 in | 125 °C | -40 C | 30 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Flush Mount M3 Threaded Insert Top Opening | |||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.156 " | 3.96 mm | Cantilever | Gold | Female | Wire Wrap | Copper Alloy | Black | Single | Non Specified - Single Edge | 30 | 1 | 3.96 mm | 0.156 in | 125 °C | -40 C | 30 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Flush Mount Top Opening Unthreaded | |||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Cantilever | Gold | Female | Solder | Copper Alloy | Black | Single | Non Specified - Single Edge | 30 | 1 | 3.96 mm | 0.156 in | 125 °C | -40 C | 30 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Cantilever | Gold | Female | Solder | Copper Alloy | Black | Dual | Non Specified - Dual Edge | 30 | 3.96 mm | 0.156 in | 125 °C | -40 C | 15 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | 2 | 2 | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Cantilever | Gold | Female | Solder | Copper Alloy | Black | Dual | Non Specified - Dual Edge | 30 | 3.96 mm | 0.156 in | 125 °C | -40 C | 15 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Board Edge Straddle Mount | Flush Mount M3 Threaded Insert Top Opening | 2 | 2 | Card Extender | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.116 " | 2.95 mm | Cantilever | Gold | Female | Solder | Copper Alloy | Black | Dual | Non Specified - Dual Edge | 30 | 3.96 mm | 0.156 in | 125 °C | -40 C | 15 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Board Edge Straddle Mount | Floating Bobbin Flush Mount | 2 | 2 | Card Extender | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.128 " | 3.25 mm | Cantilever | Gold | Female | Wire Wrap | Copper Alloy | Black | Dual | Non Specified - Dual Edge | 30 | 3.96 mm | 0.156 in | 125 °C | -40 C | 15 | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 2 | 2 |
