846-028 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 28POS 0.125
| Part | Termination Rows [custom] | Material - Insulation | Number of Positions/Bay/Row | Number of Rows [custom] | Mounting Type | Termination | Gender | Card Thickness [Max] | Card Thickness [Min] | Number of Positions | Contact Type | Flange Feature | Color | Contact Material | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Pitch | Pitch | Card Type | Read Out | Operating Temperature [Max] | Operating Temperature [Min] | Flange Feature [diameter] | Flange Feature [diameter] | Termination Rows | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 14 | 2 | Through Hole | Solder | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 28 | Cantilever | 4-40 Flush Mount Threaded Insert Top Opening | Green | Copper Alloy | Gold | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | Non Specified - Dual Edge | Dual | 125 °C | -40 C | ||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 14 | 2 | Through Hole | Solder | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 28 | Cantilever | Flush Mount Side Opening Unthreaded | Green | Copper Alloy | Gold | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | Non Specified - Dual Edge | Dual | 125 °C | -40 C | 0.128 " | 3.25 mm | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 28 | Through Hole | Solder | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 28 | Cantilever | 4-40 Flush Mount Threaded Insert Top Opening | Green | Copper Alloy | Gold | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | Non Specified - Single Edge | Single | 125 °C | -40 C | 1 | 1 | ||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 14 | 2 | Through Hole | Solder Eyelet(s) | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 28 | Cantilever | Floating Bobbin Top Mount Opening | Green | Copper Alloy | Gold | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | Non Specified - Dual Edge | Dual | 125 °C | -40 C | 0.116 " | 2.95 mm | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 28 | Through Hole | Solder Eyelet(s) | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 28 | Cantilever | Green | Copper Alloy | Gold | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | Non Specified - Single Edge | Single | 125 °C | -40 C | 1 | 1 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 28 | Through Hole | Solder | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 28 | Cantilever | 4-40 Threaded Insert Top Mount Opening | Green | Copper Alloy | Gold | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | Non Specified - Single Edge | Single | 125 °C | -40 C | 1 | 1 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 28 | Through Hole | Solder | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 28 | Cantilever | Flush Mount Top Opening Unthreaded | Green | Copper Alloy | Gold | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | Non Specified - Single Edge | Single | 125 °C | -40 C | 0.128 " | 3.25 mm | 1 | 1 | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 14 | 2 | Through Hole | Wire Wrap | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 28 | Cantilever | Flush Mount M3 Threaded Insert Top Opening | Green | Copper Alloy | Gold | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | Non Specified - Dual Edge | Dual | 125 °C | -40 C | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 28 | Through Hole | Solder Eyelet(s) | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 28 | Cantilever | 4-40 Flush Mount Threaded Insert Top Opening | Green | Copper Alloy | Gold | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | Non Specified - Single Edge | Single | 125 °C | -40 C | 1 | 1 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 28 | Through Hole | Solder | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 28 | Cantilever | 4-40 Threaded Insert Top Mount Opening | Green | Copper Alloy | Gold | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | Non Specified - Single Edge | Single | 125 °C | -40 C | 1 | 1 |
