846-007 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 7POS 0.125
| Part | Material - Insulation | Termination Rows | Contact Finish | Number of Rows | Operating Temperature [Max] | Operating Temperature [Min] | Read Out | Number of Positions/Bay/Row | Contact Material | Gender | Number of Positions | Card Type | Contact Finish Thickness | Contact Finish Thickness | Card Thickness [Max] | Card Thickness [Min] | Termination | Color | Mounting Type | Contact Type | Pitch | Pitch | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | 1 | 125 °C | -40 C | Single | 7 | Copper Alloy | Female | 7 | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Green | Right Angle Through Hole | Cantilever | 3.18 mm | 0.125 in | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | 1 | 125 °C | -40 C | Single | 7 | Copper Alloy | Female | 7 | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Green | Through Hole | Cantilever | 3.18 mm | 0.125 in | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | 1 | 125 °C | -40 C | Single | 7 | Copper Alloy | Female | 7 | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder Eyelet(s) | Green | Through Hole | Cantilever | 3.18 mm | 0.125 in | 0.128 " | 3.25 mm | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | 1 | 125 °C | -40 C | Single | 7 | Copper Alloy | Female | 7 | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | Green | Through Hole | Cantilever | 3.18 mm | 0.125 in | Flush Mount M3 Threaded Insert Top Opening | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | 1 | 125 °C | -40 C | Single | 7 | Copper Alloy | Female | 7 | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Green | Right Angle Through Hole | Cantilever | 3.18 mm | 0.125 in | Flush Mount M3 Threaded Insert Top Opening | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | 1 | 125 °C | -40 C | Single | 7 | Copper Alloy | Female | 7 | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Green | Through Hole | Cantilever | 3.18 mm | 0.125 in | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | 1 | 125 °C | -40 C | Single | 7 | Copper Alloy | Female | 7 | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | Green | Through Hole | Cantilever | 3.18 mm | 0.125 in | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | 1 | 125 °C | -40 C | Single | 7 | Copper Alloy | Female | 7 | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Green | Right Angle Through Hole | Cantilever | 3.18 mm | 0.125 in | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | 1 | 125 °C | -40 C | Single | 7 | Copper Alloy | Female | 7 | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder Eyelet(s) | Green | Through Hole | Cantilever | 3.18 mm | 0.125 in | M3 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | 1 | 125 °C | -40 C | Single | 7 | Copper Alloy | Female | 7 | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | Green | Through Hole | Cantilever | 3.18 mm | 0.125 in | 4-40 Flush Mount Threaded Insert Top Opening |
