851-87 Series
Manufacturer: Preci-Dip
Beta
⌘K
CONN SOCKET 11P 0.05 GOLD SMD RA
| Part | Contact Material | Insulation Material | Contact Shape | Connector Type | Number of Positions | Insulation Color | Number of Positions Loaded | Contact Finish - Mating | Pitch - Mating | Pitch - Mating | Mounting Type | Contact Finish Thickness - Mating | Termination | Fastening Type | Number of Rows | Material Flammability Rating | Operating Temperature [Min] | Operating Temperature [Max] | Insulation Height | Insulation Height | Contact Finish - Post | Contact Type | Contact Length - Post | Contact Length - Post |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Preci-Dip | Beryllium Copper | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Socket | 11 | Black | All | Gold | 1.27 mm | 0.05 in | Right Angle Surface Mount | Flash | Solder | Push-Pull | 1 | UL94 V-0 | -55 C | 125 °C | 0.087 " | 2.2 mm | Tin | Female Socket | ||
 Preci-Dip | Beryllium Copper | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Socket | 35 | Black | All | Gold | 1.27 mm | 0.05 in | Right Angle Surface Mount | Flash | Solder | Push-Pull | 1 | UL94 V-0 | -55 C | 125 °C | 0.087 " | 2.2 mm | Tin | Female Socket | ||
Preci-Dip | Beryllium Copper | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Socket | 25 | Black | All | Gold | 1.27 mm | 0.05 in | Right Angle Surface Mount | Flash | Solder | Push-Pull | 1 | UL94 V-0 | -55 C | 125 °C | 0.087 " | 2.2 mm | Tin | Female Socket | ||
 Preci-Dip | Beryllium Copper | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Socket | 38 | Black | All | Gold | 1.27 mm | 0.05 in | Right Angle Through Hole | Flash | Solder | Push-Pull | 1 | UL94 V-0 | -55 C | 125 °C | 0.087 " | 2.2 mm | Tin | Female Socket | 0.118 in | 3 mm |
Preci-Dip | Beryllium Copper | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Socket | 20 | Black | All | Gold | 1.27 mm | 0.05 in | Right Angle Surface Mount | Flash | Solder | Push-Pull | 1 | UL94 V-0 | -55 C | 125 °C | 0.087 " | 2.2 mm | Tin | Female Socket | ||
 Preci-Dip | Beryllium Copper | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Socket | 46 | Black | All | Gold | 1.27 mm | 0.05 in | Surface Mount | Flash | Solder | Push-Pull | 1 | UL94 V-0 | -55 C | 125 °C | 0.203 in | 5.16 mm | Tin | Female Socket | ||
Preci-Dip | Beryllium Copper | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Socket | Black | All | Gold | 1.27 mm | 0.05 in | Surface Mount | Flash | Solder | Push-Pull | 1 | UL94 V-0 | -55 C | 125 °C | 0.203 in | 5.16 mm | Tin | Female Socket | |||
Preci-Dip | Beryllium Copper | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Socket | 15 | Black | All | Gold | 1.27 mm | 0.05 in | Right Angle Through Hole | Flash | Solder | Push-Pull | 1 | UL94 V-0 | -55 C | 125 °C | 0.087 " | 2.2 mm | Tin | Female Socket | 0.118 in | 3 mm |
 Preci-Dip | Beryllium Copper | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Socket | 36 | Black | All | Gold | 1.27 mm | 0.05 in | Right Angle Surface Mount | Flash | Solder | Push-Pull | 1 | UL94 V-0 | -55 C | 125 °C | 0.087 " | 2.2 mm | Tin | Female Socket | ||
Preci-Dip | Beryllium Copper | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Socket | 18 | Black | All | Gold | 1.27 mm | 0.05 in | Right Angle Surface Mount | Flash | Solder | Push-Pull | 1 | UL94 V-0 | -55 C | 125 °C | 0.087 " | 2.2 mm | Tin | Female Socket |
