NZ04205 Series
Manufacturer: Amphenol Anytek
Beta
⌘K
WIRE-TO-BOARD TERMINAL BLOCK, 7.5 MM, 4 POSITIONS, 24 AWG, 10 AWG, PUSH IN LOCK
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Voltage | Positions Per Level | Pitch [x] | Pitch [x] | Number of Levels | Wire Gauge [Max] | Wire Gauge [Min] | Features | Color | Mounting Type | Wire Termination | Current | Mating Orientation | Housing Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol Anytek | -40 °C | 115 °C | 600 V | 3 | 0.295 in | 7.5 mm | 1 | 24 AWG | 10 AWG | Interlocking (Side) Lever Actuated | Green | Through Hole | Screwless - Spring Cage Tension Clamp | 30 A | Angled | Thermoplastic |
