202C632 Series

Manufacturer: TE Connectivity Aerospace, Defense and Marine

Catalog

BLOW-MOLDED PARTS

Part	Total Length Recovered	Total Length Recovered	Large Diameter Recovered [diameter]	Large Diameter Recovered [diameter]	Small Recovered Length	Small Recovered Length	Material	Large Diameter Supplied [diameter]	Large Diameter Supplied [diameter]	Shell Size - Insert	Type	Small Diameter Supplied [diameter]	Small Diameter Supplied [diameter]	Color	Small Diameter Recovered [diameter]	Small Diameter Recovered [diameter]	Small Recovered Length [x]
TE Connectivity Aerospace, Defense and Marine 806235N002	5.75 in	146.05 mm	0.69 in	17.53 mm	22.35 mm	0.88 in	VPB Flexible	1.34 in	34.04 mm	32	Boot	26.92 mm	1.06 in	Black	12.7 mm	0.5 "
TE Connectivity Aerospace, Defense and Marine 202C632-71/42-0-CS5818	5.75 in	146.05 mm	0.69 in	17.53 mm	22.35 mm	0.88 in	Polyolefin (PO) Flexible	1.5 in	38.1 mm	32	Boot	38.1 mm	1.5 in	Black	12.7 mm	0.5 "
TE Connectivity Aerospace, Defense and Marine 202C632-50-0-CS5325	5.75 in	146.05 mm	0.69 in	17.53 mm	22.35 mm	0.88 in	VPB Flexible	1.34 in	34.04 mm	32	Boot	26.92 mm	1.06 in	Black	12.7 mm	0.5 "
TE Connectivity Aerospace, Defense and Marine 202C632-51-0-CS5673	5.75 in	146.05 mm	0.69 in	17.53 mm	22.35 mm	0.88 in	EPB Flexible	1.34 in	34.04 mm	32	Boot	26.92 mm	1.06 in	Black	12.7 mm	0.5 "
TE Connectivity Aerospace, Defense and Marine 202C632-51-0-CS8692	5.75 in	146.05 mm	0.69 in	17.53 mm	22.35 mm	0.88 in	EPB Flexible	1.34 in	34.04 mm	32	Boot	26.92 mm	1.06 in	Black	12.7 mm	0.5 "
TE Connectivity Aerospace, Defense and Marine 202C632-71-0	5.752 in	146.1 mm	0.69 in	17.53 mm	22.4 mm		Polyolefin (PO) Flexible	1.5 in	38.1 mm	32	Boot	38.1 mm	1.5 in	Black	12.7 mm	0.5 "	0.882 in
TE Connectivity Aerospace, Defense and Marine 202C632-71/42-0	5.752 in	146.1 mm	0.69 in	17.53 mm	22.4 mm		Polyolefin (PO) Flexible	1.5 in	38.1 mm	32	Boot	38.1 mm	1.5 in	Black	12.7 mm	0.5 "	0.882 in
TE Connectivity Aerospace, Defense and Marine 202C632-51-0-CS5325	5.75 in	146.05 mm	0.69 in	17.53 mm	22.35 mm	0.88 in	EPB Flexible	1.34 in	34.04 mm	32	Boot	26.92 mm	1.06 in	Black	12.7 mm	0.5 "
TE Connectivity Aerospace, Defense and Marine 202C632-51-0	5.752 in	146.1 mm	0.69 in	17.53 mm	22.4 mm		EPB	1.34 in	34.04 mm	32	Boot	26.92 mm	1.06 in	Black	12.7 mm	0.5 "	0.882 in
TE Connectivity Aerospace, Defense and Marine 202C632-50-CS-2065-0
