HE10WPR Series

Catalog

EUROSTRIP 6P15MM FLATBASE 50A 30

Part	Bottom Termination	Current Rating	Wire Gauge (AWG) (Max)	Wire Gauge (AWG) (Min)	Color	Number of Rows	Top Termination	Number of Wire Entries	Barrier Type	Voltage Rating	Terminal Block Type	Number of Circuits	Pitch	Terminal Screw Material	Material Flammability Rating	Operating Temperature (Min)	Operating Temperature (Max)	Terminal Screw Finish	Material - Insulation	Mounting Type
Altech Corporation HE10WPR/06	Closed	50 A	18 AWG	8 AWG	White	2	Screws	12	Enclosed	300 VAC/DC	Eurostyle Terminal Strip	6	0.394 in
Altech Corporation HE10WPR/12	Closed	50 A	18 AWG	8 AWG	White	2	Screws	24	Enclosed	300 VAC/DC	Eurostyle Terminal Strip	12	0.591 in	Steel	UL94 V-0	-30 °C	125 °C	Blue Chromate	Nylon 6/6 PA66 Polyamide	Chassis Panel
Altech Corporation HE10WPR/03	Closed	50 A	18 AWG	8 AWG	White	2	Screws	6	Enclosed	300 VAC/DC	Eurostyle Terminal Strip	3	0.591 in	Steel	UL94 V-0	-30 °C	125 °C	Blue Chromate	Nylon 6/6 PA66 Polyamide	Chassis Panel
Altech Corporation HE10WPR/05	Closed	50 A	18 AWG	8 AWG	White	2	Screws	10	Enclosed	300 VAC/DC	Eurostyle Terminal Strip	5	0.394 in
Altech Corporation HE10WPR/11	Closed	50 A	18 AWG	8 AWG	White	2	Screws	22	Enclosed	300 VAC/DC	Eurostyle Terminal Strip	11	0.591 in
Altech Corporation HE10WPR/04	Closed	50 A	18 AWG	8 AWG	White	2	Screws	8	Enclosed	300 VAC/DC	Eurostyle Terminal Strip	4	0.394 in
Altech Corporation HE10WPR/09	Closed	50 A	18 AWG	8 AWG	White	2	Screws	18	Enclosed	300 VAC/DC	Barrier Block	9	0.591 in
Altech Corporation HE10WPR/10	Closed	50 A	18 AWG	8 AWG	White	2	Screws	20	Enclosed	300 VAC/DC	Barrier Block	10	0.591 in
Altech Corporation HE10WPR/07	Closed	50 A	18 AWG	8 AWG	White	2	Screws	14	Enclosed	300 VAC/DC	Barrier Block	7	0.591 in
