Z-PACK FB Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
HIGH SPEED / MODULAR CONNECTORS 2MM FB,ASY,144,SIG REC,SL,3.53
| Part | Connector Type | Features | Color | Mounting Type | Number of Positions | Connector Style | Termination | Pitch [x] | Pitch [x] | Contact Finish | Number of Positions Loaded | Number of Rows | Contact Finish Thickness | Contact Finish Thickness | Material Flammability Rating | Operating Temperature [Min] | Operating Temperature [Max] | Voltage Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | Receptacle Female Sockets | Spacer | Natural | Board Edge Right Angle Through Hole | 144 | Futurebus | Solder | 0.079 in | 2 mm | Gold | All | |||||||
TE Connectivity AMP Connectors | Receptacle Female Sockets | Spacer | Natural | Board Edge Right Angle Through Hole | 300 | Futurebus | Solder | 0.079 in | 2 mm | Gold | All | 5 | ||||||
 TE Connectivity AMP Connectors | Header Male Pins | Board Guide | Through Hole | 24 | Futurebus | Solder | 0.079 in | 2 mm | Gold | All | 30 Áin | 0.76 Ám | ||||||
 TE Connectivity AMP Connectors | Receptacle Female Sockets | Board Guide Spacer | Natural | Board Edge Right Angle Through Hole | 24 | Futurebus | Solder | 0.079 in | 2 mm | Gold | All | UL94 V-0 | -55 C | 125 °C | 30 VDC | |||
 TE Connectivity AMP Connectors | Header Male Pins | Natural | Through Hole | 48 | Futurebus | Press-Fit | 0.079 in | 2 mm | Gold | All | UL94 V-0 | -55 C | 125 °C | 30 VDC | ||||
 TE Connectivity AMP Connectors | Receptacle Female Sockets | Spacer | Natural | Board Edge Right Angle Through Hole | 192 | Futurebus | Solder | 0.079 in | 2 mm | Gold | All | |||||||
 TE Connectivity AMP Connectors | Receptacle Female Sockets | Board Guide Spacer | Natural | Board Edge Right Angle Through Hole | 96 | Futurebus | Solder | 0.079 in | 2 mm | Gold | All | UL94 V-0 | -55 C | 125 °C | 30 VDC | |||
 TE Connectivity AMP Connectors | Header Male Pins | Natural | Through Hole | 192 | Futurebus | Press-Fit | 0.079 in | 2 mm | Gold | All | UL94 V-0 | -55 C | 125 °C | 30 VDC | ||||
 TE Connectivity AMP Connectors | Header Male Pins | Board Guide | Natural | Through Hole | 60 | Futurebus | Solder | 0.079 in | 2 mm | Gold | All | 5 | ||||||
 TE Connectivity AMP Connectors | Header Male Pins | Through Hole | 192 | Futurebus | Press-Fit | 0.079 in | 2 mm | Gold | All | UL94 V-0 | -55 C | 125 °C | 30 VDC |
