DE03D Series

Catalog

DC DC CONVERTER +/-12V 3W

Part	Power (Watts)	Voltage - Output 1	Operating Temperature [Max]	Operating Temperature [Min]	Current - Output (Max)	Package / Case	Number of Outputs	Voltage - Output 2	Voltage - Input (Min) [Min]	Applications	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Mounting Type	Voltage - Input (Max) [Max]	Features	Voltage - Isolation	Type	Efficiency	Current - Output (Max)	Current - Output (Max)
Delta Electronics DE03D2412A	3 W	12 V	71 °C	-25 °C	125 mA	24-DIP Module 8 Leads	2	-12 V	18 V	Medical	0.8 "	0.4 "	31.8 mm	10.2 mm	20.3 mm	1.25 in	Through Hole	36 V	OCP SCP UVLO	1.5 kV	Isolated Module
Delta Electronics DE03D1205A	3 W	5 V	71 °C	-25 °C	250 mA	24-DIP Module 8 Leads	2	-5 V	9 V	Medical	0.8 "	0.4 "	31.8 mm	10.2 mm	20.3 mm	1.25 in	Through Hole	18 V	OCP SCP UVLO	1.5 kV	Isolated Module	77 %
Delta Electronics DE03D2415A	3 W	15 V	71 °C	-25 °C		24-DIP Module 8 Leads	2	-15 V	18 V	Medical	0.8 "	0.4 "	31.8 mm	10.2 mm	20.3 mm	1.25 in	Through Hole	36 V	OCP SCP UVLO	1.5 kV	Isolated Module		100 mA	100 mA
