Ultra-Fit Vertical Header, 3.50mm Pitch, Single Row, 7 Circuits, with Kinked Pins, Tin (Sn), Glow-Wire Capable, Black
Ultra-Fit Vertical Header, 3.50mm Pitch, Single Row, 7 Circuits, with Kinked Pins, Tin (Sn), Glow-Wire Capable, Black
Ultra-Fit Vertical Header, 3.50mm Pitch, Single Row, 7 Circuits, with Kinked Pins, Tin (Sn), Glow-Wire Capable, Black
| Part | Termination | Material Flammability Rating | Features | Number of Positions | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Shrouding | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Contact Shape | Contact Finish - Post | Applications | Insulation Height | Insulation Height | Insulation Color | Contact Length - Post | Contact Length - Post [x] | Pitch - Mating | Pitch - Mating | Voltage Rating | Style | Number of Positions Loaded | Fastening Type | Contact Material | Number of Rows | Connector Type | Contact Type | Mated Stacking Heights | Insulation Material | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish - Mating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | Kinked Pin Solder | UL94 V-0 | Board Guide | 2 | 60 Áin | 1.52 Ám | Shrouded - 4 Wall | 60 µin | 1.52 µm | Square | Tin | Automotive General Purpose Industrial Lighting Medical Military Telecommunications | 0.465 in | 11.8 mm | Black | 3.2 mm | 0.126 in | 0.138 in | 3.5 mm | 600 V | Board to Board Cable | All | Latch Holder | Copper Alloy | 1 | Header | Male Pin | 26.99 mm | Liquid Crystal Polymer (LCP) | Through Hole | -40 °C | 105 ░C | |
 Molex | Kinked Pin Solder | UL94 V-0 | Board Guide | 8 | 30 Áin | 0.76 Ám | Shrouded - 4 Wall | 60 µin | 1.52 µm | Square | Tin | Automotive General Purpose Industrial Lighting Medical Military Telecommunications | 0.465 in | 11.8 mm | Black | 3.2 mm | 0.126 in | 0.138 in | 3.5 mm | 600 V | Board to Board Cable | All | Latch Holder | Copper Alloy | 1 | Header | Male Pin | 26.99 mm | Liquid Crystal Polymer (LCP) | Through Hole | -40 °C | 120 °C | Gold |
 Molex | Kinked Pin Solder | UL94 V-0 | Board Guide | 8 | 30 Áin | 0.76 Ám | Shrouded - 4 Wall | 60 µin | 1.52 µm | Square | Tin | Automotive General Purpose Industrial Lighting Medical Military Telecommunications | 0.465 in | 11.8 mm | Natural | 3.2 mm | 0.126 in | 0.138 in | 3.5 mm | 600 V | Board to Board Cable | All | Latch Holder | Copper Alloy | 1 | Header | Male Pin | 26.99 mm | Liquid Crystal Polymer (LCP) | Through Hole | -40 °C | 120 °C | Gold |
 Molex | Kinked Pin Solder | UL94 V-0 | Board Guide | 7 | 30 Áin | 0.76 Ám | Shrouded - 4 Wall | 60 µin | 1.52 µm | Square | Tin | Automotive General Purpose Industrial Lighting Medical Military Telecommunications | 0.465 in | 11.8 mm | Black | 3.2 mm | 0.126 in | 0.138 in | 3.5 mm | 600 V | Board to Board Cable | All | Latch Holder | Copper Alloy | 1 | Header | Male Pin | 26.99 mm | Liquid Crystal Polymer (LCP) | Through Hole | -40 °C | 120 °C | Gold |
Molex | Kinked Pin Solder | UL94 V-0 | Board Guide | 7 | 15 µin | 0.38 µm | Shrouded - 4 Wall | 60 µin | 1.52 µm | Square | Tin | Automotive General Purpose Industrial Lighting Medical Military Telecommunications | 0.465 in | 11.8 mm | Black | 3.2 mm | 0.126 in | 0.138 in | 3.5 mm | 600 V | Board to Board Cable | All | Latch Holder | Copper Alloy | 1 | Header | Male Pin | 26.99 mm | Liquid Crystal Polymer (LCP) | Through Hole | -40 °C | 120 °C | Gold |
 Molex | Kinked Pin Solder | UL94 V-0 | Board Guide | 60 Áin | 1.52 Ám | Shrouded - 4 Wall | 60 µin | 1.52 µm | Square | Tin | Automotive General Purpose Industrial Lighting Medical Military Telecommunications | 0.465 in | 11.8 mm | Natural | 3.2 mm | 0.126 in | 0.138 in | 3.5 mm | 600 V | Board to Board Cable | All | Latch Holder | Copper Alloy | 1 | Header | Male Pin | 26.99 mm | Liquid Crystal Polymer (LCP) | Through Hole | -40 °C | 105 ░C | ||
 Molex | Kinked Pin Solder | UL94 V-0 | Board Guide | 4 | 60 Áin | 1.52 Ám | Shrouded - 4 Wall | 60 µin | 1.52 µm | Square | Tin | Automotive General Purpose Industrial Lighting Medical Military Telecommunications | 0.465 in | 11.8 mm | Black | 3.2 mm | 0.126 in | 0.138 in | 3.5 mm | 600 V | Board to Board Cable | All | Latch Holder | Copper Alloy | 1 | Header | Male Pin | 26.99 mm | Liquid Crystal Polymer (LCP) | Through Hole | -40 °C | 105 ░C | |
 Molex | Kinked Pin Solder | UL94 V-0 | Board Guide | 4 | 30 Áin | 0.76 Ám | Shrouded - 4 Wall | 60 µin | 1.52 µm | Square | Tin | Automotive General Purpose Industrial Lighting Medical Military Telecommunications | 0.465 in | 11.8 mm | Black | 3.2 mm | 0.126 in | 0.138 in | 3.5 mm | 600 V | Board to Board Cable | All | Latch Holder | Copper Alloy | 1 | Header | Male Pin | 26.99 mm | Liquid Crystal Polymer (LCP) | Through Hole | -40 °C | 120 °C | Gold |
 Molex | Kinked Pin Solder | UL94 V-0 | Board Guide | 15 µin | 0.38 µm | Shrouded - 4 Wall | 60 µin | 1.52 µm | Square | Tin | Automotive General Purpose Industrial Lighting Medical Military Telecommunications | 0.465 in | 11.8 mm | Natural | 3.2 mm | 0.126 in | 0.138 in | 3.5 mm | 600 V | Board to Board Cable | All | Latch Holder | Copper Alloy | 1 | Header | Male Pin | 26.99 mm | Liquid Crystal Polymer (LCP) | Through Hole | -40 °C | 120 °C | Gold | |
 Molex | Kinked Pin Solder | UL94 V-0 | Board Guide | 6 | 30 Áin | 0.76 Ám | Shrouded - 4 Wall | 60 µin | 1.52 µm | Square | Tin | Automotive General Purpose Industrial Lighting Medical Military Telecommunications | 0.465 in | 11.8 mm | Natural | 3.2 mm | 0.126 in | 0.138 in | 3.5 mm | 600 V | Board to Board Cable | All | Latch Holder | Copper Alloy | 1 | Header | Male Pin | 26.99 mm | Liquid Crystal Polymer (LCP) | Through Hole | -40 °C | 120 °C | Gold |
