W1AF1C-P Series
Manufacturer: ODU
Beta
⌘K
ODU MINI-SNAP RT. ANGLE PLUG, ST
| Part | Backshell Material, Plating | Features | Voltage Rating | Applications | Shielding | Contact Material | Insert Material | Primary Material | Number of Positions | Material Flammability Rating | Current Rating (Amps) | Operating Temperature [Max] | Operating Temperature [Min] | Cable Opening [Max] | Cable Opening [Min] | Cable Opening [Min] | Cable Opening [Max] | Shell Finish | Color | Orientation [custom] | Mounting Type | Contact Finish - Mating | Ingress Protection | Shell Material | Fastening Type | Connector Type | Shell Size - Insert [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Brass Chrome over Nickel | Backshell | 400 V | Industrial Medical Military Testing Equipment & Measurement | Unshielded | Brass | Polyetheretherketone (PEEK) | Metal | 12 | UL94 V-0 | 6 A | 120 °C | -40 C | 0.217 in | 5 mm | 0.197 in | 5.5 mm | Chrome over Nickel | Silver | 1 | Free Hanging (In-Line) Right Angle | Gold | IP50 - Dust Protected | Brass | Push-Pull | Plug Male Pins | 1.5 |
