171-009 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN D-SUB RCPT 9POS PNL MNT
| Part | Color | Contact Form | Wire Gauge [Max] | Wire Gauge [Min] | Operating Temperature [Max] | Operating Temperature [Min] | Dielectric Material | Connector Style | Current Rating (Amps) | Contact Finish Thickness | Number of Rows [custom] | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Material Flammability Rating | Contact Finish | Number of Positions | Flange Feature | Contact Type | Mounting Type | Connector Type | Termination | Shell Material, Finish | Contact Material | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Black | Stamped | 28 AWG | 19.5 AWG | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) | D-Sub | 5 A | Flash | 2 | 1 | DE E | UL94 V-0 | Gold | 9 | Housing/Shell (Unthreaded) | Signal | Panel Mount | Receptacle Female Sockets | ||||
 NorComp Inc. | Black | Stamped | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) | D-Sub | 5 A | Flash | 2 | 1 | DE E | UL94 V-0 | Gold | 9 | 4-40 | Signal | Panel Mount Through Hole | Receptacle Female Sockets | Solder | |||||
NorComp Inc. | Black | Stamped | 28 AWG | 19.5 AWG | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) | D-Sub | 5 A | Flash | 2 | 1 | DE E | UL94 V-0 | Gold | 9 | Housing/Shell (Unthreaded) | Signal | Panel Mount | Receptacle Female Sockets | ||||
 NorComp Inc. | Black | Stamped | 28 AWG | 19.5 AWG | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) Glass Filled | D-Sub | 5 A | Flash | 2 | 1 | DE E | UL94 V-0 | Gold | 9 | Cable Side (4-40) | Signal | Panel Mount | Receptacle Female Sockets | Nickel Plated Steel | |||
 NorComp Inc. | Black | Stamped | 100 °C | -50 °C | Nylon 9T Polyamide (PA9T) | D-Sub | 5 A | Flash | 2 | 1 | DE E | UL94 V-0 | Gold | 9 | Board Side (4-40) Mating Side Female Screwlock (4-40) | Signal | Panel Mount Through Hole | Receptacle Female Sockets | Solder | Nickel Plated Steel | Brass | Board Lock | ||
NorComp Inc. | Black | Stamped | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) | D-Sub | 5 A | Flash | 2 | 1 | DE E | UL94 V-0 | Gold | 9 | 4-40 | Signal | Panel Mount Through Hole | Plug Male Pins | Solder | Grounding Indents | ||||
 NorComp Inc. | Black | Stamped | 28 AWG | 19.5 AWG | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) Glass Filled | D-Sub | 5 A | Flash | 2 | 1 | DE E | UL94 V-0 | Gold | 9 | Cable Side (4-40) | Signal | Panel Mount | Receptacle Female Sockets | Nickel Plated Steel | |||
NorComp Inc. | Black | Stamped | 28 AWG | 19.5 AWG | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) | D-Sub | 5 A | Flash | 2 | 1 | DE E | UL94 V-0 | Gold | 9 | Cable Side (4-40) | Signal | Panel Mount | Plug Male Pins | Grounding Indents | |||
NorComp Inc. | Black | Stamped | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) | D-Sub | 5 A | Flash | 2 | 1 | DE E | UL94 V-0 | Gold | 9 | Board Side (4-40) | Signal | Panel Mount Through Hole | Plug Male Pins | Solder | Grounding Indents | ||||
 NorComp Inc. | Black | Stamped | 100 °C | -50 °C | Nylon 9T Polyamide (PA9T) | D-Sub | 5 A | Flash | 2 | 1 | DE E | UL94 V-0 | Gold | 9 | Board Side (4-40) | Signal | Panel Mount Through Hole | Receptacle Female Sockets | Solder | Nickel Plated Steel | Brass |
