MPA Series

Catalog

SENSOR LIN 431MM CBL W/CONN

Part	Output [Max]	Output [Min]	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Supply [Min]	Voltage - Supply [Max]	Package / Case	Mounting Type	Linear Range [Min]	Linear Range [Max]	Linear Range [Max]	Linear Range [Min]	Actuator Type	For Measuring	Technology	Termination Style
SICK, Inc. 1059460	20 mA	4 mA	70 °C	-20 °C	15 VDC	30 VDC	Module	Chassis Mount	0 mm	431 mm	16.97 "	0 "	T-Slot	Linear Position	Magnetoresistive	Cable with Connector
SICK, Inc. 1059454	20 mA	4 mA	70 °C	-20 °C	15 VDC	30 VDC	Module	Chassis Mount	0 mm	323 mm	12.72 "	0 "	T-Slot	Linear Position	Magnetoresistive	Cable with Connector
SICK, Inc. MPA-503THTP0	20 mA	4 mA	70 °C	-20 °C	15 VDC	30 VDC	Module	Chassis Mount	0 mm	19.8 in 503 mm			T-Slot	Linear Position	Magnetoresistive	Cable with Connector
SICK, Inc. 1059476	20 mA	4 mA	70 °C	-20 °C	15 VDC	30 VDC	Module	Chassis Mount	0 mm	899 mm	35.39 "	0 "	T-Slot	Linear Position	Magnetoresistive	Cable with Connector
SICK, Inc. 1059475	20 mA	4 mA	70 °C	-20 °C	15 VDC	30 VDC	Module	Chassis Mount	0 mm	863 mm	33.98 "	0 "	T-Slot	Linear Position	Magnetoresistive	Cable with Connector
SICK, Inc. 1059465	20 mA	4 mA	70 °C	-20 °C	15 VDC	30 VDC	Module	Chassis Mount	0 mm	19.8 in 503 mm			T-Slot	Linear Position	Magnetoresistive	Cable
SICK, Inc. 1059444	20 mA	4 mA	70 °C	-20 °C	15 VDC	30 VDC	Module	Chassis Mount					T-Slot	Linear Position	Magnetoresistive	Cable with Connector
SICK, Inc. 1059461	20 mA	4 mA	70 °C	-20 °C	15 VDC	30 VDC	Module	Chassis Mount	0 mm	431 mm	16.97 "	0 "	T-Slot	Linear Position	Magnetoresistive	Cable
SICK, Inc. 1059447	20 mA	4 mA	70 °C	-20 °C	15 VDC	30 VDC	Module	Chassis Mount	0 mm	179 mm	7.05 in	0 "	T-Slot	Linear Position	Magnetoresistive	Cable
SICK, Inc. 1059457	20 mA	4 mA	70 °C	-20 °C	15 VDC	30 VDC	Module	Chassis Mount	0 mm	359 mm	14.13 in	0 "	T-Slot	Linear Position	Magnetoresistive	Cable
