JN514 Series

Manufacturer: Freescale Semiconductor - NXP

Catalog

IC RF TXRX+MCU 802.15.4 40HVQFN

Part	Protocol	RF Family/Standard	Operating Temperature [Max]	Operating Temperature [Min]	Sensitivity	Voltage - Supply [Max]	Voltage - Supply [Min]	Current - Transmitting	Supplier Device Package	Package / Case	Memory Size	Type	Mounting Type	Current - Receiving	Frequency	Power - Output	Memory Size [custom]	Memory Size [custom]	Data Rate (Max)	GPIO	Modulation	Serial Interfaces	Antenna Type
Freescale Semiconductor - NXP JN5142N/J01,518	Zigbee®	802.15.4	125 °C	-40 °C	-95 dBm	3.6 V	2 V	15 mA	40-HVQFN (6x6)	40-VFQFN Exposed Pad	32 kB 128 kB	TxRx + MCU	Surface Mount	16.5 mA	2.4 GHz	2.5 dBm
Freescale Semiconductor - NXP JN5148/J01,515	Zigbee®	802.15.4	85 °C	-40 °C	-96.5 dBm	3.6 V	2 V	15 mA	56-HVQFN (8x8)	56-VFQFN Exposed Pad		TxRx + MCU	Surface Mount	17.5 mA	2.4 GHz	2.75 dBm	128 kB	128 kB	667 kbps	21	O-QPSK	I2C JTAG SPI UART
Freescale Semiconductor - NXP JN5148/J01,518	Zigbee®	802.15.4	85 °C	-40 °C	-96.5 dBm	3.6 V	2 V	15 mA	56-HVQFN (8x8)	56-VFQFN Exposed Pad		TxRx + MCU	Surface Mount	17.5 mA	2.4 GHz	2.75 dBm	128 kB	128 kB	667 kbps	21	O-QPSK	I2C JTAG SPI UART
Freescale Semiconductor - NXP JN5148/001M04T,534	Zigbee®	802.15.4	85 °C	-40 °C	-98 dBm	3.6 V	2.7 V	110 mA		Module			Surface Mount	23 mA	2.4 GHz	20 dBm	128 kB	128 kB				I2C SPI UART	Antenna Not Included U.FL
Freescale Semiconductor - NXP JN5148/001,531	Zigbee®	802.15.4	85 °C	-40 °C	-96.5 dBm	3.6 V	2 V	15 mA		56-VFQFN		TxRx + MCU		17.5 mA	2.4 GHz	2.75 dBm	128 kB	128 kB	667 kbps	21	O-QPSK	I2C JTAG SPI UART
Freescale Semiconductor - NXP JN5142N/J01,515	Zigbee®	802.15.4	125 °C	-40 °C	-95 dBm	3.6 V	2 V	15 mA	40-HVQFN (6x6)	40-VFQFN Exposed Pad	32 kB 128 kB	TxRx + MCU	Surface Mount	16.5 mA	2.4 GHz	2.5 dBm
Freescale Semiconductor - NXP JN5142N/001,515	Zigbee®	802.15.4	125 °C	-40 °C	-95 dBm	3.6 V	2 V	15 mA	40-HVQFN (6x6)	40-VFQFN Exposed Pad	32 kB 128 kB	TxRx + MCU	Surface Mount	16.5 mA	2.4 GHz	2.5 dBm
