1744214 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
CONN HEADER VERT 6POS 2.54MM
| Part | Insulation Height | Insulation Height | Contact Material | Current Rating (Amps) | Contact Shape | Contact Type | Number of Positions | Insulation Material | Contact Finish - Post | Pitch - Mating | Pitch - Mating | Operating Temperature [Max] | Operating Temperature [Min] | Insulation Color | Applications | Contact Length - Post [x] | Contact Length - Post [x] | Overall Contact Length | Overall Contact Length | Style | Mounting Type | Number of Rows | Contact Length - Mating | Contact Length - Mating | Fastening Type | Shrouding | Number of Positions Loaded | Connector Type | Material Flammability Rating | Termination | Voltage Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | 0.305 in | 7.75 mm | Copper Alloy | Varies by Wire Gauge | Square | Male Pin | 6 | Thermoplastic | Tin | 0.1 in | 2.54 mm | 105 ░C | -55 °C | Natural | General Purpose | 3.56 mm | 0.14 in | 0.535 in | 13.59 mm | Board to Cable/Wire | Through Hole | 1 | 7.49 mm | 0.295 in | Friction Lock | Shrouded - 1 Wall | All | Header | UL94 V-0 | Solder | 250 VAC |
