315-47 Series

Manufacturer: Mill-Max Manufacturing Corp.

Catalog

CONN RCPT 18POS 0.1 GOLD PCB

Part	Contact Shape	Contact Material	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Insulation Material	Contact Length - Post	Contact Length - Post	Contact Finish - Post	Number of Positions	Contact Finish - Mating	Operating Temperature [Min]	Operating Temperature [Max]	Contact Type	Pitch - Mating	Pitch - Mating	Number of Rows	Material Flammability Rating	Voltage Rating	Voltage Rating	Termination	Current Rating (Amps)	Insulation Color	Mounting Type	Contact Finish Thickness - Mating	Connector Type	Fastening Type	Number of Positions Loaded	Contact Length - Post	Insulation Height	Insulation Height	Insulation Height [z]	Insulation Height [z]	Number of Positions [custom]
Mill-Max Manufacturing Corp. 315-47-118-41-001000	Circular	Beryllium Copper	200 µin	5.08 µm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.108 in	2.75 mm	Tin	18	Gold	-55 C	125 °C	Female Socket	0.1 "	2.54 mm	1	UL94 V-0	100 V	150 VDC	Solder	3 A	Black	Through Hole	Flash	Receptacle	Push-Pull	All
Mill-Max Manufacturing Corp. 315-47-149-41-001000	Circular	Beryllium Copper	200 µin	5.08 µm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.108 in	2.75 mm	Tin	49	Gold	-55 C	125 °C	Female Socket	0.1 "	2.54 mm	1	UL94 V-0	100 V	150 VDC	Solder	3 A	Black	Through Hole	Flash	Receptacle	Push-Pull	All
Mill-Max Manufacturing Corp. 315-47-150-41-003000	Circular	Beryllium Copper	200 µin	5.08 µm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester		0.095 in	Tin	50	Gold	-55 C	125 °C	Female Socket	0.1 "	2.54 mm	1	UL94 V-0	100 V	150 VDC	Solder	3 A	Black	Through Hole	Flash	Receptacle	Push-Pull	All	2.41 mm	1.8 mm	0.071 in
Mill-Max Manufacturing Corp. 315-47-102-41-004000	Circular	Beryllium Copper	200 µin	5.08 µm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.082 in	2.08 mm	Tin	2	Gold	-55 C	125 °C	Female Socket	0.1 "	2.54 mm	1		100 V	150 VDC	Solder	3 A	Black	Through Hole	Flash	Socket	Push-Pull	All				1.27 mm	0.05 in
Mill-Max Manufacturing Corp. 315-47-106-41-004000	Circular	Beryllium Copper	200 µin	5.08 µm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.082 in	2.08 mm	Tin	6	Gold	-55 C	125 °C	Female Socket	0.1 "	2.54 mm	1		100 V	150 VDC	Solder	3 A	Black	Through Hole	Flash	Socket	Push-Pull	All				1.27 mm	0.05 in
Mill-Max Manufacturing Corp. 315-47-105-41-003000	Circular	Beryllium Copper	200 µin	5.08 µm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester		0.095 in	Tin	5	Gold	-55 C	125 °C	Female Socket	0.1 "	2.54 mm	1	UL94 V-0	100 V	150 VDC	Solder	3 A	Black	Through Hole	Flash	Receptacle	Push-Pull	All	2.41 mm	1.8 mm	0.071 in
Mill-Max Manufacturing Corp. 315-47-143-41-001000	Circular	Beryllium Copper	200 µin	5.08 µm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.108 in	2.75 mm	Tin	43	Gold	-55 C	125 °C	Female Socket	0.1 "	2.54 mm	1	UL94 V-0	100 V	150 VDC	Solder	3 A	Black	Through Hole	Flash	Receptacle	Push-Pull	All
Mill-Max Manufacturing Corp. 315-47-134-41-003000	Circular	Beryllium Copper	200 µin	5.08 µm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester		0.095 in	Tin		Gold	-55 C	125 °C	Female Socket	0.1 "	2.54 mm	1	UL94 V-0	100 V	150 VDC	Solder	3 A	Black	Through Hole	Flash	Receptacle	Push-Pull	All	2.41 mm	1.8 mm	0.071 in			34
Mill-Max Manufacturing Corp. 315-47-103-41-003000	Circular	Beryllium Copper	200 µin	5.08 µm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester		0.095 in	Tin		Gold	-55 C	125 °C	Female Socket	0.1 "	2.54 mm	1	UL94 V-0	100 V	150 VDC	Solder	3 A	Black	Through Hole	Flash	Receptacle	Push-Pull	All	2.41 mm	1.8 mm	0.071 in
Mill-Max Manufacturing Corp. 315-47-132-41-003000	Circular	Beryllium Copper	200 µin	5.08 µm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester		0.095 in	Tin		Gold	-55 C	125 °C	Female Socket	0.1 "	2.54 mm	1	UL94 V-0	100 V	150 VDC	Solder	3 A	Black	Through Hole	Flash	Receptacle	Push-Pull	All	2.41 mm	1.8 mm	0.071 in
