PUC2405 Series
Manufacturer: Flex Power Modules
Beta
⌘K
DC DC CONVERTER 5V 1W
| Part | Current - Output (Max) [Max] | Voltage - Input (Min) [Min] | Operating Temperature [Min] | Operating Temperature [Max] | Applications | Mounting Type | Type | Package / Case | Efficiency | Standard Number | Approval Agency | Voltage - Input (Max) [Max] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Number of Outputs | Voltage - Output 1 | Features | Voltage - Isolation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Flex Power Modules | 200 mA | 21.6 V | -40 °C | 100 °C | ITE (Commercial) | Through Hole | Isolated Module | 4-SIP Module | 78 % | 62368-1 | cURus IEC UL | 26.4 V | 11.5 mm | 0.78 " | 7.1 mm | 0.28 in | 0.45 in | 19.7 mm | 1 | 5 V | Adjustable Output | 6000 VDC |
