502443 Series
2.00mm Pitch CLIK-Mate Wire-to-Board PCB Receptacle, Single Row, Vertical, 3 Circuits
Manufacturer: Molex
Catalog
2.00mm Pitch CLIK-Mate Wire-to-Board PCB Receptacle, Single Row, Vertical, 3 Circuits
Beta
⌘K
2.00mm Pitch CLIK-Mate Wire-to-Board PCB Receptacle, Single Row, Vertical, 3 Circuits
2.00mm Pitch CLIK-Mate Wire-to-Board PCB Receptacle, Single Row, Vertical, 3 Circuits
2.00mm Pitch CLIK-Mate Wire-to-Board PCB Receptacle, Single Row, Vertical, 3 Circuits
| Part | Contact Shape | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Insulation Material | Contact Material | Contact Finish - Post | Mounting Type | Number of Positions | Material Flammability Rating | Insulation Height | Insulation Height | Contact Finish Thickness - Mating [custom] | Contact Finish Thickness - Mating [custom] | Connector Type | Fastening Type | Pitch - Mating | Pitch - Mating | Insulation Color | Features | Number of Rows | Style | Number of Positions Loaded | Contact Type | Termination | Current Rating (Amps) | Voltage Rating | Operating Temperature [Min] | Operating Temperature [Max] | Applications | Current Rating (Amps) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | Rectangular | 39.4 çin | 1 çm | Nylon Polyamide (PA) | Copper Alloy | Tin | Surface Mount | 9 | UL94 V-0 | 0.293 in | 7.44 mm | 39.4 µin | 1 µm | Receptacle | Detent Lock | 0.079 " | 2 mm | Natural | Solder Retention | 1 | Board to Cable/Wire | All | Forked | Solder | Varies by Wire Gauge | 250 VAC | -40 C | 105 ░C | ||
 Molex | Rectangular | 39.4 çin | 1 çm | Nylon Polyamide (PA) | Copper Alloy | Tin | Surface Mount | 13 | UL94 V-0 | 0.293 in | 7.44 mm | 39.4 µin | 1 µm | Receptacle | Detent Lock | 0.079 " | 2 mm | Natural | Solder Retention | 1 | Board to Cable/Wire | All | Forked | Solder | Varies by Wire Gauge | 250 VAC | -40 C | 105 ░C | ||
 Molex | 39.4 çin | 1 çm | Resin | Copper Alloy | Tin | Surface Mount | 6 | UL94 V-0 | 0.293 in | 7.44 mm | 39.4 µin | 1 µm | Receptacle | Latch Holder | 0.079 " | 2 mm | Natural | Solder Retention | 1 | Board to Cable/Wire | All | Forked | Solder | -40 C | 105 ░C | Automotive General Purpose Industrial Lighting Medical | ||||
 Molex | Rectangular | 39.4 çin | 1 çm | Nylon Polyamide (PA) | Copper Alloy | Tin | Surface Mount | 7 | UL94 V-0 | 0.293 in | 7.44 mm | 39.4 µin | 1 µm | Receptacle | Detent Lock | 0.079 " | 2 mm | Natural | Solder Retention | 1 | Board to Cable/Wire | All | Forked | Solder | Varies by Wire Gauge | 250 VAC | -40 C | 105 ░C | ||
 Molex | 39.4 çin | 1 çm | Nylon Polyamide (PA) | Copper Alloy | Tin | Surface Mount | 15 | UL94 V-0 | 0.293 in | 7.44 mm | 39.4 µin | 1 µm | Receptacle | Latch Holder | 0.079 " | 2 mm | Natural | Solder Retention | 1 | Board to Cable/Wire | All | Female Socket | Solder | 250 VAC | -40 C | 105 ░C | 3 A | |||
 Molex | 39.4 çin | 1 çm | Resin | Copper Alloy | Tin | Surface Mount | 7 | UL94 V-0 | 0.293 in | 7.44 mm | 39.4 µin | 1 µm | Receptacle | Latch Holder | 0.079 " | 2 mm | Natural | Solder Retention | 1 | Board to Cable/Wire | All | Forked | Solder | -40 C | 105 ░C | Automotive General Purpose Industrial Lighting Medical | ||||
Molex | 39.4 çin | 1 çm | Nylon Polyamide (PA) | Copper Alloy | Tin | Surface Mount | 8 | UL94 V-0 | 0.293 in | 7.44 mm | 39.4 µin | 1 µm | Receptacle | Latch Holder | 0.079 " | 2 mm | Natural | Pick and Place Solder Retention | 1 | Board to Cable/Wire | All | Forked | Solder | 250 V | -40 C | 105 ░C | Automotive General Purpose Industrial Lighting Medical | 3 A | ||
 Molex | 39.4 çin | 1 çm | Resin | Copper Alloy | Tin | Surface Mount | 5 | UL94 V-0 | 0.293 in | 7.44 mm | 39.4 µin | 1 µm | Receptacle | Latch Holder | 0.079 " | 2 mm | Natural | Solder Retention | 1 | Board to Cable/Wire | All | Forked | Solder | -40 C | 105 ░C | Automotive General Purpose Industrial Lighting Medical | ||||
 Molex | Rectangular | 39.4 çin | 1 çm | Nylon Polyamide (PA) | Copper Alloy | Tin | Surface Mount | 14 | UL94 V-0 | 0.293 in | 7.44 mm | 39.4 µin | 1 µm | Receptacle | Detent Lock | 0.079 " | 2 mm | Natural | Solder Retention | 1 | Board to Cable/Wire | All | Forked | Solder | Varies by Wire Gauge | 250 VAC | -40 C | 105 ░C | ||
 Molex | 39.4 çin | 1 çm | Resin | Copper Alloy | Tin | Surface Mount | 15 | UL94 V-0 | 0.293 in | 7.44 mm | 39.4 µin | 1 µm | Receptacle | Latch Holder | 0.079 " | 2 mm | Natural | Solder Retention | 1 | Board to Cable/Wire | All | Forked | Solder | -40 C | 105 ░C | Automotive General Purpose Industrial Lighting Medical |
