IRM-10 Series
Manufacturer: MEAN WELL USA Inc.
Beta
⌘K
AC/DC CONVERTER 12V 10W
| Part | Load Regulation | Line Regulation | Mounting Type | Number of Outputs | Voltage - Output 1 | Power (Watts) | Applications | Operating Temperature [Min] | Operating Temperature [Max] | Package / Case | Features | Approval Agency | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [z] | Type | Current - Output (Max) [Max] | Voltage - Input [Max] | Voltage - Input [Min] | Efficiency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 MEAN WELL USA Inc. | 0.5 % | 0.3 % | Through Hole | 1 | 12 V | 10 W | ITE (Commercial) | -30 °C | 70 °C | 4-DIP Module | Universal Input | CB CE cURus EAC TUV | 1.8 in | 45.7 mm | 1 " | 25.4 mm | 21.5 mm | 0.85 " | Enclosed | 850 mA | 305 VAC 430 VDC | 85 VAC 120 VDC | |
MEAN WELL USA Inc. | 0.5 % | 0.3 % | Through Hole | 1 | 5 V | 10 W | ITE (Commercial) | -30 °C | 70 °C | 4-DIP Module | Universal Input | CB CE cURus EAC TUV | 1.8 in | 45.7 mm | 1 " | 25.4 mm | 21.5 mm | 0.85 " | Enclosed | 2 A | 305 VAC 430 VDC | 85 VAC 120 VDC | 77 % |
MEAN WELL USA Inc. | 0.5 % | 0.3 % | Through Hole | 1 | 3.3 V | 8.25 W | ITE (Commercial) | -30 °C | 70 °C | 4-DIP Module | Universal Input | CB CE cURus EAC TUV | 1.8 in | 45.7 mm | 1 " | 25.4 mm | 21.5 mm | 0.85 " | Enclosed | 2.5 A | 305 VAC 430 VDC | 85 VAC 120 VDC | 74 % |
