896-028 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 28POS 0.125
| Part | Termination Rows [custom] | Material - Insulation | Contact Finish Thickness | Contact Finish Thickness | Pitch | Pitch | Operating Temperature [Max] | Operating Temperature [Min] | Number of Rows [custom] | Termination | Card Type | Number of Positions | Gender | Read Out | Number of Positions/Bay/Row | Contact Type | Color | Mounting Type | Card Thickness [Max] | Card Thickness [Min] | Contact Finish | Flange Feature | Contact Material | Termination Rows | Number of Rows | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | 125 °C | -40 C | 2 | Solder | Non Specified - Dual Edge | 28 | Female | Dual | 14 | Cantilever | Black | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Flush Mount M3 Threaded Insert Top Opening | Copper Alloy | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | 125 °C | -40 C | Solder | Non Specified - Single Edge | 28 | Female | Single | 28 | Cantilever | Black | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Flush Mount Top Opening Unthreaded | Copper Alloy | 1 | 1 | 3.25 mm | 0.128 " | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | 125 °C | -40 C | 2 | Wire Wrap | Non Specified - Dual Edge | 28 | Female | Dual | 14 | Cantilever | Black | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 4-40 Threaded Insert Top Mount Opening | Copper Alloy | |||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | 125 °C | -40 C | 2 | Solder | Non Specified - Dual Edge | 28 | Female | Dual | 14 | Cantilever | Black | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Flush Mount Top Opening Unthreaded | Copper Alloy | 3.25 mm | 0.128 " | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | 125 °C | -40 C | 2 | Solder | Non Specified - Dual Edge | 28 | Female | Dual | 14 | Cantilever | Black | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Floating Bobbin Top Mount Opening | Copper Alloy | 2.95 mm | 0.116 " | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | 125 °C | -40 C | Solder | Non Specified - Single Edge | 28 | Female | Single | 28 | Cantilever | Black | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Flush Mount Top Opening Unthreaded | Copper Alloy | 1 | 1 | 3.25 mm | 0.128 " | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | 125 °C | -40 C | 2 | Solder | Non Specified - Dual Edge | 28 | Female | Dual | 14 | Cantilever | Black | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 4-40 Flush Mount Threaded Insert Top Opening | Copper Alloy | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | 125 °C | -40 C | Solder | Non Specified - Single Edge | 28 | Female | Single | 28 | Cantilever | Black | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Side Mount Opening Unthreaded | Copper Alloy | 1 | 1 | 3.25 mm | 0.128 " | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | 125 °C | -40 C | 2 | Solder | Non Specified - Dual Edge | 28 | Female | Dual | 14 | Cantilever | Black | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Copper Alloy | 3.25 mm | 0.128 " | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | 125 °C | -40 C | 2 | Solder | Non Specified - Dual Edge | 28 | Female | Dual | 14 | Cantilever | Black | Board Edge Straddle Mount | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Floating Bobbin Top Mount Opening | Copper Alloy | 2.95 mm | 0.116 " | Card Extender |
