SLS-05 Series
Manufacturer: SolaHD
Beta
⌘K
AC/DC CONVERTER 5V 15W
| Part | Voltage - Input [Min] | Voltage - Input [Max] | Mounting Type | Features | Operating Temperature [Max] | Operating Temperature [Min] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [z] | Voltage - Output 1 | Number of Outputs | Current - Output 1 | Power (Watts) | Type | Applications | Approval Agency | Size / Dimension | Size / Dimension | Size / Dimension | Size / Dimension [y] | Size / Dimension [z] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SolaHD | 100 VAC | 240 VAC | Chassis Mount | Adjustable Output Remote Sense | 50 °C | 0 °C | 123 mm | 41.1 mm | 4.84 in | 101.4 mm | 3.99 " | 1.62 " | 5 V | 1 | 3 A | 15 W | Open Frame | ITE (Commercial) | CSA cURus | |||||
 SolaHD | 100 VAC | 240 VAC | Chassis Mount | Adjustable Output Remote Sense | 50 °C | 0 °C | 7 " | 4.87 in | 2.75 in | 5 V | 1 | 9 A | 45 W | Open Frame | ITE (Commercial) | CSA cURus | 69.9 mm | 123.7 mm | 177.8 mm | |||||
 SolaHD | 100 VAC | 240 VAC | Chassis Mount | Adjustable Output Remote Sense | 50 °C | 0 °C | 142.7 mm | 5.62 " | 4.87 in | 1.28 " | 5 V | 1 | 6 A | 30 Watts | Open Frame | ITE (Commercial) | CSA cURus | 123.7 mm | 32.5 mm | |||||
SolaHD | 100 VAC | 240 VAC | Chassis Mount | Adjustable Output Remote Sense | 50 °C | 0 °C | 228.6 mm | 69.9 mm | 9 in | 123.7 mm | 4.87 in | 2.75 in | 5 V | 1 | 12 A | 60 W | Open Frame | ITE (Commercial) | CSA cURus |
