M80-401 Series

Catalog

HEADER CONNECTOR,PCB MOUNT,RECEPT,14 CONTACTS,PIN,0.079 PITCH,PC TAIL TERMINAL,M2X0.4 ROHS COMPLIANT: YES

Part	Applications	Insulation Material	Contact Shape	Contact Material	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Style	Termination	Connector Type	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Material Flammability Rating	Mated Stacking Heights	Contact Length - Post	Contact Length - Post	Contact Finish - Mating	Pitch - Mating	Pitch - Mating	Row Spacing - Mating	Row Spacing - Mating	Mounting Type	Contact Finish - Post	Number of Rows [custom]	Features	Number of Positions	Operating Temperature [Min]	Operating Temperature [Max]	Insulation Height	Insulation Height	Number of Positions Loaded	Voltage Rating	Contact Type	Insulation Color
Harwin Inc. M80-4011442	Automotive General Purpose Military	Polyphenylene Sulfide (PPS) Glass Filled	Circular	Beryllium Copper	3.5 Ám	137.8 Áin	Board to Board Cable	Solder	Receptacle	12 Áin	0.3 Ám	UL94 V-0	7.3 mm 7.55 mm	4.6 mm	0.181 in	Gold	0.079 "	2 mm	2 mm	0.079 in	Through Hole	Tin	2	Jackscrews Mating Flange Mounting Flange Polarizing Key	14	-55 C	125 °C	5.2 mm	0.205 "	All	120 VDC	Female Socket	Black
Harwin Inc. M80-4010642	Automotive General Purpose Military	Polyphenylene Sulfide (PPS) Glass Filled	Circular	Beryllium Copper	3.5 Ám	137.8 Áin	Board to Board Cable	Solder	Receptacle	12 Áin	0.3 Ám	UL94 V-0	7.3 mm 7.55 mm	4.6 mm	0.181 in	Gold	0.079 "	2 mm	2 mm	0.079 in	Through Hole	Tin	2	Jackscrews Mating Flange Mounting Flange Polarizing Key	6	-55 C	125 °C	5.2 mm	0.205 "	All	120 VDC	Female Socket	Black
Harwin Inc. M80-4015001	Automotive General Purpose Military	Polyphenylene Sulfide (PPS) Glass Filled	Circular	Beryllium Copper	3.5 Ám	137.8 Áin	Board to Board Cable	Solder	Receptacle	12 Áin	0.3 Ám	UL94 V-0	7.3 mm 7.55 mm	4.6 mm	0.181 in	Gold	0.079 "	2 mm	2 mm	0.079 in	Through Hole	Tin-Lead	2	Jackscrews Mating Flange Mounting Flange Polarizing Key	50	-55 C	125 °C	5.2 mm	0.205 "	All	120 VDC	Female Socket	Black
Harwin Inc. M80-4011242	Automotive General Purpose Military	Polyphenylene Sulfide (PPS) Glass Filled	Circular	Beryllium Copper	3.5 Ám	137.8 Áin	Board to Board Cable	Solder	Receptacle	12 Áin	0.3 Ám	UL94 V-0	7.3 mm 7.55 mm	4.6 mm	0.181 in	Gold	0.079 "	2 mm	2 mm	0.079 in	Through Hole	Tin	2	Jackscrews Mating Flange Mounting Flange Polarizing Key	12	-55 C	125 °C	5.2 mm	0.205 "	All	120 VDC	Female Socket	Black
Harwin Inc. M80-4011201	Automotive General Purpose Military	Polyphenylene Sulfide (PPS) Glass Filled	Circular	Beryllium Copper	3.5 Ám	137.8 Áin	Board to Board Cable	Solder	Receptacle	12 Áin	0.3 Ám	UL94 V-0	7.3 mm 7.55 mm	4.6 mm	0.181 in	Gold	0.079 "	2 mm	2 mm	0.079 in	Through Hole	Tin-Lead	2	Jackscrews Mating Flange Mounting Flange Polarizing Key	12	-55 C	125 °C	5.2 mm	0.205 "	All	120 VDC	Female Socket	Black
Harwin Inc. M80-4011042	Automotive General Purpose Military	Polyphenylene Sulfide (PPS) Glass Filled	Circular	Beryllium Copper	3.5 Ám	137.8 Áin	Board to Board Cable	Solder	Receptacle	12 Áin	0.3 Ám	UL94 V-0	7.3 mm 7.55 mm	4.6 mm	0.181 in	Gold	0.079 "	2 mm	2 mm	0.079 in	Through Hole	Tin	2	Jackscrews Mating Flange Mounting Flange Polarizing Key	10	-55 C	125 °C	5.2 mm	0.205 "	All	120 VDC	Female Socket	Black
Harwin Inc. M80-4011001	Automotive General Purpose Military	Polyphenylene Sulfide (PPS) Glass Filled	Circular	Beryllium Copper	3.5 Ám	137.8 Áin	Board to Board Cable	Solder	Receptacle	12 Áin	0.3 Ám	UL94 V-0	7.3 mm 7.55 mm	4.6 mm	0.181 in	Gold	0.079 "	2 mm	2 mm	0.079 in	Through Hole	Tin-Lead	2	Jackscrews Mating Flange Mounting Flange Polarizing Key	10	-55 C	125 °C	5.2 mm	0.205 "	All	120 VDC	Female Socket	Black
Harwin Inc. M80-4014242	Automotive General Purpose Military	Polyphenylene Sulfide (PPS) Glass Filled	Circular	Beryllium Copper	3.5 Ám	137.8 Áin	Board to Board Cable	Solder	Receptacle	12 Áin	0.3 Ám	UL94 V-0	7.3 mm 7.55 mm	4.6 mm	0.181 in	Gold	0.079 "	2 mm	2 mm	0.079 in	Through Hole	Tin	2	Jackscrews Mating Flange Mounting Flange Polarizing Key	42	-55 C	125 °C	5.2 mm	0.205 "	All	120 VDC	Female Socket	Black
